Molex Pico-Clasp Series Right Angle Surface PCB Header 30 Contact 1 mm Pitch 2 Row Shrouded 501571-3007

Molex 501571-3007 Pico-Clasp Series Right Angle Surface PCB Header is a high-density wire-to-board connector designed with 30 contacts arranged in 2 rows at a 1 mm pitch. This dual-row connector provides a secure and shrouded interface with a right angle orientation for versatile PCB surface mounting applications.

The housing is constructed from robust nylon material, offering durability and insulation in demanding industrial environments. The contacts are plated with gold to ensure excellent electrical conductivity and resistance to corrosion, supporting reliable signal integrity.

Operating temperature range extends from -40°C to 105°C, making it suitable for various harsh operating conditions found in industrial, automotive, and consumer electronics sectors. It carries a rated current of 1 amp and a working voltage up to 50 volts, catering to low power control and signal transmission needs.

Termination is through solder, suitable for automated surface mount manufacturing processes. The positive locking feature inside the headers secures mating and helps prevent accidental disconnects during mechanical vibration or handling.

This connector complies with key environmental and safety standards including ELV, Low halogen, REACH, RoHS, and UL, ensuring responsible material content and reliability in electronic assemblies.

The Pico-Clasp series is recognized for its very compact 1.00 mm pitch spacing, enabling high-density PCB layouts in compact form factors. It is ideal for industrial, manufacturing, commercial electronics, and laboratory applications which demand dependable wire-to-board connections in tight spaces.

Available on reels for efficient machine insertion and production use, this connector supports improved assembly throughput and product quality. The connector features a dual-row configuration with 2 rows for compact wiring.

Housing is made of durable nylon material to ensure insulation and mechanical support. Contacts are gold plated for excellent conductivity and corrosion resistance. The header is shrouded with right angle orientation for secure mating and PCB mounting.

Designed to operate from -40°C to 105°C maintaining stable performance. It has a current rating of 1 amp and voltage rating of 50 volts for standard signal applications. Termination type is solder for surface mount assembly on PCB.

Conforms to ELV, Low halogen, REACH, RoHS, and UL standards ensuring environmental compliance. Mating pin length is 1 mm suitable for compatible wire-to-board connections.
