IQD 32.768 kHz Crystal Unit Surface Mount 2-Pin 3.2 x 1.5 x 0.9 mm ±20 ppm LFXTAL009678

Free Delivery in India | Lowest Global Shipping Charges

IQD 32.768 kHz Crystal Unit Surface Mount 2-Pin 3.2 x 1.5 x 0.9 mm ±20 ppm LFXTAL009678



Category Electronic Components Brand IQD Condition New

Specifications

Country of Origin	India
Brand	IQD
Height	0.9mm
Length	3.2mm
Model	LFXTAL009678
Width	1.5mm
Mount Type	Surface
Series	CFPX-217
Maximum Operating Temperature	85°C
Package Type	Surface Mount
Minimum Operating Temperature	-40°C
Standards/Approvals	EU, REACH, RoHS 2011
Pin Count	2
Standard Frequency	32.768kHz
Load Capacitance	12.5pF
Series Resistance	70kΩ

Key Features

Operates at a standard frequency of 32.768 kHz with ±20 ppm tolerance.
Compact surface mount package measuring 3.2 mm length, 1.5 mm width, and 0.9 mm height.
Designed with a 2-pin configuration suitable for soldering on PCB surfaces.
Load capacitance rated at 12.5 pF for stable oscillation.
Hermetically sealed ceramic package with a metal lid ensures long-term reliability.
Wide operating temperature range from -40°C to 85°C for varied environments.
Series resistance of 70 kΩ meeting CFPX-217 series specifications.
Compliance with EU, REACH, and RoHS 2011 standards ensuring environmental safety.

Product Description

IQD LFXTAL009678 32.768 kHz Crystal Unit Surface Mount 2-Pin is a precision electronic component designed for frequency stabilization and timing applications. Operating at a standard frequency of 32.768 kHz with a frequency tolerance and stability of ±20 ppm, this crystal unit ensures accurate timing signals indispensable in clocks, microcontrollers, and other low-frequency electronic devices.

The device is packaged in a compact 3.2 mm × 1.5 mm × 0.9 mm surface mount ceramic enclosure featuring a hermetically sealed metal lid that lends robust environmental protection, enhancing reliability over extended service life.

Its 2-pin surface mount configuration and 12.5 pF load capacitance facilitate straightforward PCB integration with minimal parasitic effects. The crystal exhibits a series resistance of 70 kΩ consistent with the CFPX-217 series standards, optimizing its oscillation performance.

Designed to operate reliably within a broad temperature spectrum ranging from -40°C to 85°C, it meets stringent EU, REACH, and RoHS 2011 compliance criteria, making it suitable for various industrial, consumer, and instrumentation applications where environmental regulations are paramount.

Precise 32.768 kHz standard frequency for timing applications. Compact surface mount form factor with 2 pins for easy installation. Hermetically sealed ceramic package ensures durability and stability. Wide operating temperature range from -40°C to 85°C.

Compliance with EU, REACH, and RoHS 2011 environmental standards. Series resistance of 70 kΩ suited to CFPX-217 series specifications. Load capacitance of 12.5 pF for stable oscillator operation. Extensively used in consumer electronics, instrumentation, and industrial devices.

Not designed for automotive standard applications. Ensures dependable frequency control in diverse electronic equipment.

This crystal unit is an essential component for engineers and designers engaged in developing devices requiring precise timekeeping and frequency stabilization. Its rugged construction and certified compliance enhance reliability and facilitate usage across multiple sectors including industrial electronics, consumer products, and instrumentation.
