Crydom GN Series Solid State Relay Panel Mount 25A Load 660V AC Load 32V DC Control 84137110

Crydom 84137110 Solid State Relay in GN Series is designed for panel mounting applications requiring reliable and efficient switching of industrial loads. This solid-state relay supports a maximum load current of 25A and can handle AC loads up to 660V, controlled by a DC voltage range from 3V to 32V. Its SCR output type provides fast and durable switching without mechanical wear, ideal for lighting, HVAC, and automation systems.

Engineered for durability, it operates safely in extreme temperatures from -40°C to 80°C, making it suitable for harsh industrial environments. The integrated anti-rotation barriers ensure vibration-proof mounting, enhancing installation reliability. An IP20 rated cover protects users from accidental contact, allowing finger-safe operation while guarding against solid objects greater than 12 mm.

Key technical advantages include zero cross switching which minimizes electrical interference and prolongs equipment life, a minimal off-state leakage current of 0.25mArms to reduce power loss, and fast switching times within half an AC cycle. The relay is UL and CE certified, ensuring compliance with international safety standards.

The compact form factor measures 44.5mm in length and 30.9mm in height, with screw terminals for secure electrical connections. Manufactured in Mexico, this relay brings high reliability with an MTBF of 1,328 years at 40°C, promising long-term operational performance. Typical applications include industrial automation, electrical panels, HVAC controls, and load switching in manufacturing processes.

Designed for panel mounting with sturdy screw terminals for secure installation. Supports a maximum load current of 25 amperes for medium-duty industrial applications. Operates safely within a temperature range of -40°C to 80°C.

Features zero cross switching for reducing electrical noise and stress. Has IP20 rated cover to protect against solid objects and provide finger-safe handling. Constructed with SCR based output type for efficient solid-state switching.

Compact dimensions of 44.5mm length and 30.9mm height for space-saving installation. Certified under UL and CE standards ensuring quality and safety compliance. Very low off-state leakage current of 0.25mArms enhancing energy efficiency.

Explore more high-quality Solid State Relays and control solutions in the Electronics & Electricals category at EnvMart.
