SMC Pneumatic Compact Cylinder Double Acting Aluminium Alloy Body 20mm Bore 80mm Stroke CD55B20-80
Specifications
| Country of Origin | France |
|---|---|
| Brand | SMC |
| Body Material | Aluminium Alloy |
| Maximum Operating Pressure | 1.5 Mpa |
| Height | 36mm |
| Length | 123mm |
| Model | CD55B20-80 |
| Gross Weight | 306g |
| Width | 36mm |
| Mount Type | Through Hole |
| Series | CD55 |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -10°C |
| Stroke Length | 80mm |
| Bore Diameter | 20mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Standards/Approvals | ISO 21287 |
| Cushioning Type | Rubber |
| Piston Rod Gender | Female |
| Piston Rod Thread Standard | Metric |
| Piston Rod Thread Size | 10 mm |
Key Features
- Double acting pneumatic cylinder for precise linear motion control.
- Compact aluminium alloy body with hard anodized finish for durability.
- 20mm bore and 80mm stroke length suitable for compact automation setups.
- Maximum operating pressure 1.5 Mpa and piston speed up to 500 mm/s.
- Through hole mount type with single rod and female metric threaded piston rod.
- Rubber cushioning for smooth operation and noise reduction.
- Operating temperature range from -10°C to 70°C for diverse environments.
- Conforms to ISO 21287 standards ensuring quality and interchangeability.
Product Description
SMC CD55B20-80 Pneumatic Compact Cylinder is a precision double acting actuator designed for industrial applications requiring compact size and reliable linear motion. Featuring a 20mm bore and 80mm stroke length, this cylinder is engineered with a hard anodized aluminium alloy body ensuring excellent corrosion resistance and lightweight design, suitable for automated machinery and fluid power systems.
The cylinder supports a maximum operating pressure of 1.5 Mpa and can operate piston speeds of up to 500 mm/s. The through hole mounting type allows easy installation in confined spaces. Rubber cushioning provides reduced impact and noise during operation, enhancing durability and worker comfort.
The piston rod is single type with female metric thread size 10mm, allowing standard compatibility with industrial fittings. It operates effectively in temperatures ranging from -10°C to 70°C, making it versatile for various environmental conditions.
This product complies with ISO 21287 standards, promoting interchangeability and quality assurance in pneumatic systems.
Dimensions include a length of 123mm, height and width each 36mm, making it apt for compact installations. The gross weight of 306 grams contributes to ease of handling and integration within automation lines.
Double acting pneumatic cylinder for precise linear motion control. Compact aluminium alloy body with hard anodized finish for durability. 20mm bore and 80mm stroke length suitable for compact automation setups. Maximum operating pressure 1.5 Mpa and piston speed up to 500 mm/s.
Through hole mount type with single rod and female metric threaded piston rod. Rubber cushioning for smooth operation and noise reduction. Operating temperature range from -10°C to 70°C for diverse environments. Conforms to ISO 21287 standards ensuring quality and interchangeability.
Lightweight design with gross weight of 306 g suitable for industrial automation. Ideal for industrial automation, pneumatic systems, manufacturing, and fluid power applications. Discover more Pneumatic Cylinders and actuators in the Industrial Tools & Equipment category on EnvMart for efficient automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 1.5 Mpa.
The dimensions of this cylinder are a length of 123mm, height of 36mm, and width of 36mm.
This unit has a stroke length of 80mm.
The bore diameter of this model is 20mm.
It operates effectively within a temperature range of -10°C to 70°C.
This model is equipped with rubber cushioning for smooth operation and noise reduction.
The gross weight of this cylinder is 306 grams.
The piston rod is a single type with a female metric thread size of 10mm.
This unit features a through hole mount type for easy installation.
It conforms to ISO 21287 standards, ensuring quality and interchangeability.
The maximum piston speed of this model can reach up to 500 mm/s.
This pneumatic cylinder is suitable for industrial automation, pneumatic systems, manufacturing, and fluid power applications.
