ROHM 40 V 1 A Schottky Barrier Diode Surface Mount SOD-123FL Package RB168MM-40TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 0.8mm |
| Length | 2.6mm |
| Model | RB168MM-40TR |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | RB168MM-40 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-123FL |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | JEDEC : SOD-123FL, ROHM : PMDU |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 550nA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 40A |
| Maximum Forward Voltage Vf | 650mV |
| Peak Reverse Recovery Time trr | 8ns |
| Standards/ApprovalsJEDEC | SOD-123FL, ROHM : PMDU |
| JEDEC | SOD-123FL, ROHM : PMDU |
Key Features
- Features a compact SOD-123FL package suitable for surface mounting applications.
- Maximum continuous forward current of 1 ampere ensures reliable performance.
- Peak reverse repetitive voltage rated at 40 volts for robust operation.
- Low forward voltage drop of 650 millivolts improves energy efficiency.
- Fast peak reverse recovery time of 8 nanoseconds supports high-speed switching.
- Operates reliably within temperature range of -55°C to +150°C.
- Complies with JEDEC standards and automotive AEC-Q101 for quality assurance.
- Pin count of 2 supports simple circuit integration.
Product Description
The ROHM RB168MM-40TR is a highly efficient Schottky Barrier Diode designed for precise rectification needs in electronic circuits. Packaged in a compact SOD-123FL surface mount form, it is suited for modern PCB assembly processes where space is a premium.
With a maximum continuous forward current of 1A and a peak reverse repetitive voltage of 40V, this diode offers reliable performance under various industrial and commercial electronic applications. The forward voltage of 650 millivolts minimizes power losses, enhancing overall device efficiency.
Its fast peak reverse recovery time of 8 nanoseconds enables high-speed switching, making it applicable in power conversion, voltage clamping, and RF circuitry. The diode operates safely in ambient conditions ranging from -55 to 150 degrees Celsius, supporting demanding environmental standards.
The device conforms to JEDEC SOD-123FL packaging and the automotive-grade AEC-Q101 standard, assuring quality and reliability for automotive and industrial uses. Its two-pin configuration allows straightforward circuit integration.
Compact surface mount SOD-123FL package. Maximum forward current of 1A. Peak reverse voltage rating of 40V. Low forward voltage for efficient operation. Fast reverse recovery time optimized for switching. Wide operating temperature from -55°C to +150°C.
JEDEC standard compliant with AEC-Q101 automotive approval. Two-pin diode configuration.
This Schottky diode is suited for electronics manufacturing, automotive PCB assemblies, power supplies, voltage protection circuits, and various industrial electronic systems. Its robust design and certified standards make it a reliable choice for high-performance and compact electronic applications.
Browse EnvMart’s extensive collection of semiconductor and diode components for compatible parts from ROHM and other leading manufacturers.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the ROHM RB168MM-40TR is 1 ampere.
This model has a peak reverse repetitive voltage rating of 40 volts.
The forward voltage drop is 650 millivolts, which helps improve energy efficiency.
It is packaged in a compact SOD-123FL surface mount package, suitable for modern PCB assembly.
The diode operates reliably within a temperature range of -55°C to +150°C.
The peak reverse recovery time is 8 nanoseconds, supporting high-speed switching applications.
This Schottky diode has a two-pin configuration, allowing for straightforward circuit integration.
It complies with the automotive AEC-Q101 standard for quality assurance.
The dimensions are 0.8 mm in height, 2.6 mm in length, and 1.6 mm in width.
It is a Schottky rectifier, designed for efficient rectification in electronic circuits.
This model is suitable for electronics manufacturing, automotive PCB assemblies, and power supplies.
The country of origin for this diode is India.
