XP Power AH Series DC/DC Converter, 500 V dc Output, 3 mA Output Current, 5 V dc Input, Through Hole Mount, 1.5 W AH05P-5
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power AH DC/DC Converter, 500V dc/ 3 mA, 5V dc |
| Brand | XP Power |
| Length | 23.37mm |
| Model | AH05P-5 |
| Depth | 6.35mm |
| Gross Weight | 5.7g |
| Width | 11.43mm |
| Mount Type | Through Hole |
| Series | AH |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -25°C |
| MTBF | 1862000h |
| Number of outputs | 1 |
| Ripple and Noise | 0.7% Pk-Pk |
| Maximum Output Power | 1.5W |
| Maximum Input Voltage | 5V dc |
| Minimum Input Voltage | 0V dc |
| Output Voltage 1 | 500V dc |
| Output Current 1 | 3mA |
| Isolation Voltage | 500V |
Key Features
- This converter delivers a maximum output power of 1.5 W.
- Input voltage range is from 0 V to 5 V DC, ideal for precise low-power applications.
- Operating temperature ranges from -25 °C minimum to 75 °C maximum for reliable performance.
- It features galvanic input-to-output isolation with an isolation voltage of 500 V.
- The compact size includes dimensions of 23.37 mm length, 11.43 mm width, and 6.35 mm depth.
- Ripple and noise are minimal at 0.7% peak-to-peak to ensure signal integrity.
- Mount type is through hole for easy PCB integration.
- Mean Time Between Failures (MTBF) is 1,862,000 hours, indicating high reliability.
Product Description
XP Power AH05P-5 DC/DC Converter is an ultra-miniature isolated DC to high voltage DC power converter from the AH Series designed to meet demanding industrial, laboratory, and electronic circuitry requirements.
The device provides a stable 500 V DC output with a low output current of 3 mA and maximum output power rating of 1.5 W. It operates with input voltages from 0 V to 5 V DC, making it suitable for control and measurement applications where low power consumption is essential.
The AH05P-5 incorporates galvanic isolation between input and output with an isolation voltage of 500 V. Its low output/input capacitance and low leakage current on the control pin enhance accuracy and noise immunity. The quasi-sine wave oscillator design supports low ripple and noise of 0.7% peak-to-peak, preserving signal quality.
This converter is built for through hole mounting on PCBs and measures 23.37 mm by 11.43 mm by 6.35 mm, with a weight of just 5.7 grams. It is rated for operating temperatures ranging from -25 °C to 75 °C and boasts a robust Mean Time Between Failures (MTBF) of approximately 1.86 million hours, demonstrating superior reliability in critical applications.
Typical use cases include avalanche photodiodes, capacitor charging, electrophoresis, photomultiplier tubes, piezo devices, mass spectrometry, sustaining ion pumps, and other instrumentation requiring high voltage isolation and stable DC output.
This product complies with UL and RoHS standards for safety and environmental regulations. Proudly manufactured in the United States, the AH Series converters from XP Power provide dependable performance in compact form factors.
This DC/DC converter delivers 500 V output at 3 mA current with 1.5 W power. Galvanic isolation of 500 V ensures safe and noise-free operation. Operating temperature range is -25 °C to 75 °C for industrial robustness. Compact through hole mounting with small footprint dimensions.
Low ripple and noise characteristics improve signal quality. Explore more DC/DC Converters and power management solutions at EnvMart for versatile industrial, electronic, and laboratory applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output voltage of this model is 500 V DC.
It operates with an input voltage range from 0 V to 5 V DC.
The maximum output power is 1.5 W.
The output current rating is 3 mA.
This converter measures 23.37 mm in length, 11.43 mm in width, and 6.35 mm in depth.
The operating temperature range is from -25 °C to 75 °C.
It features a through hole mounting type for easy PCB integration.
The isolation voltage is 500 V, providing galvanic isolation between input and output.
The ripple and noise are minimal at 0.7% peak-to-peak.
The MTBF is approximately 1,862,000 hours, indicating high reliability.
Typical use cases include avalanche photodiodes, capacitor charging, and mass spectrometry, among others requiring high voltage isolation.
This product complies with UL and RoHS standards for safety and environmental regulations.
