XP Power AH Series Ultra Miniature Isolated DC/DC Converter, 12V dc Input, 250V dc Output, 6 mA Output Current AH025P-12

XP Power AH025P-12 DC/DC Converter is an ultra-miniature, isolated power supply designed for industrial and laboratory applications that require compactness and reliability. It operates with a 12V DC input and provides a high voltage DC output of 250V with an output current of 6mA and max output power of 1.5W. Its through hole mounting makes it easy to integrate on printed circuit boards.

With an operating temperature range from -25°C to 75°C, this converter functions reliably under varying industrial conditions. The galvanic isolation voltage of 500V between input and output protects sensitive electronic circuits while maintaining signal integrity. It includes low output/input capacitance and very low leakage current thanks to its quasi-sinewave oscillator control pin.

The device also offers a minimum one-minute short circuit protection and requires no minimum load, which simplifies system design and reduces the need for auxiliary components. It has five pins and a small footprint of 23.37 mm length by 11.43 mm width, weighing only 5.7 grams.

This DC/DC converter is suitable for sophisticated applications like avalanche photodiodes, capacitor charging, electrophoresis, photomultiplier tubes, piezoelectric devices, mass spectrometry, and sustaining ion pumps. It is a reliable choice for industrial electronics, medical devices, scientific instrumentation, and other precision equipment requiring isolated power conversion.

The device features a through hole mount suitable for compact PCB applications. Operating temperature ranges from -25°C to 75°C for robust environmental performance. Provides galvanic isolation with 500V isolation voltage ensuring safety and signal integrity.

The ripple and noise are maintained at low levels of 1.2% peak-to-peak for stable output. Ultra-low leakage current via a quasi-sinewave oscillator control pin enhances efficiency. Requires no external components and has a minimum load not required for operation.

Short circuit protection lasts at least one minute to protect connected circuits. Ideal for applications such as avalanche photodiodes, capacitor charging, photomultiplier tubes, and sustaining ion pumps.

XP Power products like the AH series DC/DC Converter are widely used in industrial, laboratory, medical, and scientific equipment deployments, where compactness, reliability, and safety are paramount. Browse EnvMart for more advanced power conversion and isolation products from leading manufacturers.
