KEMET R82 Film Capacitor, ±5% Tolerance, 68 nF, 100 V DC, 63 V AC Through Hole Mount R82EC2680DQ60J

KEMET R82EC2680DQ60J is a precision film capacitor from the R82 series, offering 68 nF capacitance with a ±5% tolerance. It is designed to operate at 100 V DC and 63 V AC voltages, making it ideal for demanding electronic circuits that require stable and reliable capacitance values.

This capacitor is built from metallised polyester film with radial leads of tinned wire electrically welded for durability. The encapsulation in a self-extinguishing, solvent-resistant plastic case with thermosetting resin provides enhanced safety and durability under various operating conditions.

The R82 series capacitors feature a lead pitch of 5 mm, lead length of 18.5 mm, and a lead diameter of 0.5 mm, enabling easy and secure through-hole mounting on PCBs. They are suitable for a range of industrial, automotive, and commercial electronics applications such as oscillator circuits, timing, coupling, decoupling, and blocking functions.

Operating reliably between temperatures of -55°C and +105°C, these capacitors conform to the IEC 60384-2 standard and RoHS compliance, ensuring environmental safety and performance. The units are also compliant with AEC-Q100 automotive standards, assuring quality and reliability in automotive electronic systems.

Typical usage includes electronic manufacturing for industrial products, automotive electronics, power supplies, and consumer electronics. The product supports applications requiring stable capacitance and reliability over broad temperature ranges and electrical stresses.

Metallised polyester film capacitor construction provides stability. Self-healing feature enhances durability under electrical stress. RoHS compliant and environmental friendly. Lead pitch suitable for standard PCB through-hole mounting.

Automotive grade compliant (AEC-Q100) for high reliability. Operating temperature range of -55°C to +105°C for versatility. Compact form factor with dimensions 7.2 mm length, 6.5 mm height, and 2.5 mm width. Encapsulated in flame-retardant, solvent-resistant plastic case.

For professional electronics assembly, this KEMET Film Capacitor model R82EC2680DQ60J is a trustworthy component widely used in industrial, commercial, and automotive sectors. For more products in the Electronics Components category, explore EnvMart’s extensive catalog.
