Renesas Electronics Instrumentation Amplifier Evaluation Board ISL28633EV2Z with 2 Bit Interface RoHS Compliant ISL28633EV2Z
Specifications
| Country of Origin | India |
|---|---|
| Brand | Renesas Electronics |
| Model | ISL28633EV2Z |
| Interface Type | 2 Bit |
| Standards/Approvals | RoHS |
| Kit Classification | Evaluation Board |
| Featured Device | ISL28633 |
| Kit Name | ISL28633EV2Z |
| Analogue Function | Instrumentation Amplifier |
| Low input offset | 5 μV, Max |
| Low inputs offset drift | 50 nV/°C, Max |
| Gain bandwidth | 2.3 MHz |
| Low gain error | 0.4%, Max |
Key Features
- This evaluation board supports pin selectable gain settings ranging from 1 to 1000 to accommodate various input signal levels.
- Operates on a single power supply voltage from 2.5 V up to 5.5 V for flexible low-voltage applications.
- Features low input offset voltage of up to 5 μV maximum and low input offset drift of 50 nV/°C maximum for stable performance.
- High common-mode rejection ratio (CMRR) of up to 138 dB at gain 100 ensures noise immunity.
- Includes RFI filtered inputs to improve electromagnetic interference (EMI) rejection, enhancing signal integrity.
- Gain bandwidth product of 2.3 MHz allows amplification of signals with considerable frequency components.
- The zero drift programmable gain amplifier technology reduces DC errors and enhances accuracy.
- Compact 2-bit interface type facilitates straightforward integration with development and testing systems.
Product Description
Renesas Electronics ISL28633EV2Z Instrumentation Amplifier Evaluation Board is designed for efficient evaluation of the ISL28633 programmable gain amplifier with high precision and stability. This analog development tool enables engineers and developers to thoroughly test and configure the ISL28633 device, suitable for applications demanding low offset, low noise, and high gain performance.
The evaluation board features pin selectable gain options that allow setting gain values from 1 to 1000, providing flexibility for a wide range of testing scenarios. It operates with a single supply voltage between 2.5 V and 5.5 V, optimized for modern low-power designs.
Low input offset voltage (maximum 5 μV) and offset drift (maximum 50 nV/°C) ensure the board's output remains stable across temperature variations, while an exceptional common-mode rejection ratio of up to 138 dB guarantees minimal signal distortion due to common-mode noise.
Inputs are filtered for Radio Frequency Interference (RFI), improving the board’s resilience against electromagnetic disturbances commonly encountered in industrial and laboratory environments.
Gain bandwidth product of 2.3 MHz supports applications requiring amplification of signals with medium to high frequency components. The zero drift architecture of the amplifier mitigates DC offset errors, making this kit ideal for precision signal conditioning and measurement tasks in research, industrial, and educational applications.
This evaluation board is RoHS compliant, reflecting a commitment to environmentally friendly manufacturing standards. This product is intended for industrial, laboratory, research, and development use. Instrumental in design and testing of analog sensor interfaces, precision measurements, and low noise amplification circuits.
Supports a broad range of programmable gain configurations for experimental flexibility.
Renesas Electronics ISL28633EV2Z Evaluation Board is a valuable component in electronics development toolkits, catering to engineers developing instrumentation amplifiers and analog front-end systems. Explore more precision analog development tools at EnvMart.
