Molex KK 254 Series Right Angle Through Hole Pin Header, 10 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-2101

Molex 22-05-2101 KK 254 Series Right Angle Through Hole Pin Header is a high-quality electronic component designed for reliable board-to-board and wire-to-board interfacing. It features 10 contacts arranged in a single row with a standard 2.54 mm pitch, ideal for precision PCB assembly and electronic system integration.

This pin header utilizes a durable white nylon housing that meets UL 94V-0 flammability standards, ensuring safety and performance under industrial conditions. The contacts are made from brass and plated with tin, providing excellent electrical conductivity and corrosion resistance. Rated for 4 amperes current and 250 volts, it supports moderate power applications commonly found in electronic devices and control systems.

The right angle orientation and through-hole mount type facilitate sturdy mechanical connection and efficient PCB layout, while the unshrouded design permits visual inspection and ease of connector engagement. Its operating temperature range extends from -40°C up to 105°C, ensuring reliable function in harsh environments.

Additional features include solder termination and male contact gender. The product has a tail pin length of 3.15 mm and mating pin length of 2.54 mm, compatible with standard female connectors. Its stackable design allows for compact and modular PCB configurations, supporting end-to-end and side-to-side assembly expansions.

This Molex KK 254 series pin header is widely used in industrial electronics, automation systems, communication devices, and consumer electronics manufacturing. It complies with UL (E29179) and CSA (LR 19980) standards, assuring quality and safety.

Supplied in bag packaging and ready for insertion into assembly machinery, this component improves production efficiency for manufacturing processes. Designed for board-to-board and wire-to-board connections. Constructed with a white nylon UL 94V-0 housing material.

Features brass contacts plated with tin for reliable conductivity. Supports a current rating of 4A and voltage rating of 250V. Fits through-hole mount style with right angle orientation. Operates reliably from -40°C to 105°C temperature range.

Termination type is solder with male contact gender. Stackable end to end and side to side for versatile PCB layouts. Tail pin length of 3.15 mm and mating pin length of 2.54 mm. Unshrouded design allows easy connector mating inspection.

Explore more high-quality PCB Headers and electronic components in our Electronics & Electricals category at EnvMart.
