Molex KK 254 Series Right Angle Through Hole Pin Header, 10 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-2101
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.15mm |
| Mating Pin Length | 2.54mm |
Key Features
- Constructed with brass contacts plated with tin ensuring good conductivity.
- Housing made of white nylon with UL 94V-0 rating for flame retardant protection.
- Supports a maximum current of 4A and voltage rating of 250V.
- Designed with a right angle orientation and unshrouded style for easy board-to-board and wire-to-board mating.
- Through-hole mount type provides reliable mechanical and electrical connection.
- Operating temperature range from -40°C up to 105°C ensures stable performance.
- Tails and mating pins measure 3.15 mm and 2.54 mm length respectively for secure solder termination.
- These headers are stackable end to end and side to side, enabling flexible PCB layout design.
Product Description
Molex 22-05-2101 KK 254 Series Right Angle Through Hole Pin Header is designed for electronic component assemblies requiring reliable board-to-board or wire-to-board connections. Featuring 10 male brass contacts plated with tin and housed in a flame-retardant white nylon body, it offers excellent electrical performance with a current capacity of 4A and a voltage rating of 250V.
The header employs a 2.54 mm pitch with a single row of unshrouded pins, facilitating straightforward solder termination via its 3.15 mm tail pins. Its right angle orientation optimizes PCB space management and enables stacking options both end to end and side to side, enhancing design flexibility.
Operating safely across a temperature range from -40°C to 105°C, this component is suitable for demanding industrial and electronic environments. It mounts through-hole ensuring robust mechanical stability, ideal for manufacturing processes requiring durable connections.
Fabricated under UL (E29179) and CSA (LR 19980) standards, this Molex header meets stringent quality and safety requirements. It serves as an essential component in industrial machinery, telecommunications, and various electronics applications.
Brass contacts with tin plating ensure low resistance connections. White nylon housing rated UL 94V-0 for flame retardancy. Supports up to 4A current and 250V voltage. Right angle, unshrouded single row design. Through-hole mounting for secure PCB installation.
Operating temperature from -40°C to 105°C. 3.15 mm tail pin length and 2.54 mm mating pin length. Stackable layout providing flexible PCB configurations. Meets UL and CSA industrial approval standards. This Molex KK 254 Series pin header is ideal for use in electronic component manufacturing, industrial automation systems, communications equipment, and PCB assembly processes.
Explore more PCB Headers and electronic components at EnvMart to support your project and production needs with premium brands and precise technical specifications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header supports a maximum current of 4A and a voltage rating of 250V.
The pitch size of this model is 2.54 mm.
It utilizes a through-hole mounting type, ensuring a secure mechanical and electrical connection.
The contacts are made of brass plated with tin, and the housing is constructed from white nylon.
The operating temperature range is from -40°C to 105°C.
This model features 10 male contacts.
The tail pins measure 3.15 mm in length.
This pin header is designed as unshrouded, facilitating easy board-to-board and wire-to-board mating.
It supports board-to-board and wire-to-board connector systems.
The housing material is rated UL 94V-0 for flame retardancy.
The mating pins have a length of 2.54 mm.
The pin header is manufactured in India.
