Burkert Stainless Steel 2 Port Normally Closed Solenoid Valve 230V AC 10 bar Max Pressure 20mm Orifice 6213 Series 141246

Burkert 141246 is a high-quality solenoid valve featuring a robust stainless steel body, designed for a range of industrial and fluid control applications. This normally closed, 2 port valve operates at 230V AC supply voltage and supports a maximum operating pressure of 10 bar with a 20mm orifice diameter, enabling precise fluid regulation in various systems.

The valve is part of the 6213 series, known for its reliability and compactness. It is suitable for fluids including fat-free oils, hydraulic oils, neutral fluids, and water, accommodating temperatures from 30°C up to 55°C. The coil is epoxy encapsulated to provide IP65 protection, ensuring durability in harsh industrial environments.

It features servo assist functionality that ensures smooth valve operation, with maximum closing and opening times of 4 seconds. The valve mounting is flexible but preferably with the coil upwards, and it uses BSP parallel ports compatible with compression fittings. The inlet thread adheres to DIN EN 175301-803 Form A standards, commonly accepted in industrial setups.

This Burkert solenoid valve is certified to UL, CSA, and other standards, with KTW/FDA approval for EPDM parts, underlining its suitability for sensitive applications including water treatment and food-grade processes. Its compact form factor and protective coil housing make it ideal for use in industrial automation, hydraulic machinery, HVAC systems, and laboratory equipment.

Constructed with stainless steel body for corrosion resistance and durability. Operates on 230V AC with 8W coil power consumption for efficient energy use. Supports fluids like neutral fluids, oils, and water with safe operation up to 55°C.

Epoxy encapsulated coil rated IP65 protects against dust and water ingress. Minimum operating temperature is 30°C with max pressure up to 10 bar. Servo assist mechanism minimizes valve actuation times for precise control.

Certified to multiple standards including UL, CSA, and DIN EN approvals. Suitable for industrial, laboratory, hydraulic, and HVAC fluid control applications.

Set contains one Burkert 141246 solenoid valve with features optimized for demanding industrial fluid control tasks. For more options and related Solenoid Valves, browse the Industrial Valves category on EnvMart.
