KEMET Film Capacitor 100 nF 630 V dc 220V ac Through Hole Radial Lead R60PI3100AA30J
Specifications
| Country of Origin | India |
|---|---|
| Capacitance Range | 0.001 μF - 150.0 μF |
| Voltage Range | 50 to 1000 V dc |
| Brand | KEMET |
| Height | 13.5mm |
| Length | 18mm |
| Model | R60PI3100AA30J |
| Packaging | Bag |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | R60 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 100nF |
| Minimum Operating Temperature | -55°C |
| Climatic category | 55/105/56 |
| Lead Length | 25mm |
| Standards/Approvals | IEC 60286-2, UL 94V-0, RoHS |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 220V ac |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±5%, ±10%, ±20% |
| Lead Spacing | 10.0 to 37.5 mm |
Key Features
- The capacitor features a radial lead with a lead pitch of 15mm.
- Operating temperature range spans from -55°C to 105°C for broad application tolerance.
- Self-extinguishing plastic case complies with UL 94V-0 standards.
- Suitable for blocking, coupling, timing, bypassing, and oscillator circuits in industrial and automotive uses.
- Meets automotive standard AEC-Q200 and IEC 60286-2 certifications.
- Provides reliability under harsh environmental conditions with plastic encapsulation.
- Lead length is 25mm with lead diameter of 0.8mm for secure soldering and installation.
- Packaging is in bags for easy handling and protection before assembly.
Product Description
KEMET R60PI3100AA30J Film Capacitor is a high-quality radial lead polymer component designed for electronic and industrial applications requiring precise capacitance and reliability.
With a capacitance of 100 nF and a tolerance of ±5 %, this capacitor supports a rated DC voltage of 630 V and rated AC voltage of 220 V ac, making it suitable for a wide range of low voltage electronic circuits and industrial systems.
The device utilizes a through-hole mounting type with a lead pitch of 15 mm and lead length of 25 mm, which facilitates stable mechanical and electrical connections on PCBs. Constructed with a self-extinguishing plastic case and thermosetting resin, it adheres to UL 94V-0 flame retardancy, ensuring safety in critical electrical environments.
Operating temperature range is from -55°C to +105°C, suitable for harsh and automotive operating conditions complying with AEC-Q200 standards. The capacitor is also RoHS compliant, making it environmentally friendly and free from hazardous substances.
Typical applications include blocking, coupling, timing, bypassing, oscillator circuits, and interference suppression in industrial automation, automotive electronics, and power supply units.
The plastic-film dielectric ensures long-term stability and low loss in signal application. Lead diameter of 0.8 mm provides durable mechanical connection with through-hole PCBs. Plastic case and lead materials resist solvents and environmental degradation.
Complies with IEC 60286-2 standard for mounting and packaging dimensions. Bag packaging provides protected supply ensuring efficient handling during production assembly. Offers electrical performance optimized for coupling, timing, and blocking functions.
For engineers and designers, the KEMET R60PI3100AA30J capacitor combines robust industrial standards with versatile applications in electronics manufacturing and automotive sectors.
Explore EnvMart's extensive catalog of electronic components to find compatible capacitors and components for your industrial and technological needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 100 nF with a tolerance of ±5%.
It supports a rated DC voltage of 630 V and a rated AC voltage of 220 V.
It features a lead pitch of 15 mm, facilitating stable connections on PCBs.
The dimensions are 18 mm in length, 7.5 mm in width, and 13.5 mm in height.
This model utilizes a through-hole mounting type, which is standard for many electronic applications.
It complies with IEC 60286-2, UL 94V-0, and is RoHS compliant, ensuring it meets various safety and environmental standards.
The lead length is 25 mm with a lead diameter of 0.8 mm, providing a secure soldering connection.
It is suitable for blocking, coupling, timing, bypassing, and oscillator circuits in industrial and automotive uses.
The capacitor is packaged in bags for easy handling and protection before assembly.
The climatic category is 55/105/56, indicating its performance in various environmental conditions.
It meets the automotive standard AEC-Q200, ensuring reliability in automotive applications.
