TE Connectivity 5-Way IDC Connector Male for Through Hole 1 Row, 7A Current, 250V AC 300V AC, Mini-Match Series 5164713-5
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250, 300V ac |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | Mini-Match |
| Termination Type | IDC |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- The connector is part of the Mini-Match series, designed for vertical PCB mounting with a pitch of 2.5mm.
- It features an unshrouded, straight orientation with male contacts.
- Contact plating includes tin over nickel, with brass material contacts for durability.
- Suitable for operating temperatures ranging from -40°C to 85°C.
- Housing is made from Polyethylene Terephthalate, ensuring robust insulation and mechanical strength.
- The connector uses IDC termination type and mounts through-hole.
- Designed for desktop computers, home entertainment equipment, remote controls, and measuring devices.
- Manufactured in India, ensuring quality and reliability.
Product Description
TE Connectivity 5164713-5 5-Way IDC Connector Male for Through Hole, 1 Row, current rating 7A, voltage 250V to 300V AC, Mini-Match series, is a high-quality electronic connector suitable for various industrial and commercial applications including electronics manufacturing, desktop computing, and measurement devices.
This vertical PCB header features a 2.5mm pitch with integrated overstress protection and high contact pressure ensuring reliable and consistent performance in demanding environments. The connector's male, unshrouded design supports through-hole mounting with a straight orientation for ease of PCB assembly.
Constructed with brass contacts plated with tin over nickel, the connector exhibits excellent conductivity and corrosion resistance. The housing is fabricated from durable Polyethylene Terephthalate, providing mechanical robustness and insulation. It is rated for operation in temperatures ranging from -40°C to 85°C, making it suitable for various climates and industrial conditions.
Applications for this IDC connector include desktop computer equipment, home entertainment systems, remote control transmitters, and other electronic measuring instruments where secure and stable PCB connections are critical.
The connector supports a current of 7A and voltage up to 300V AC. It features a 5-contact layout arranged in a single row. Termination is by insulation displacement contact (IDC) technology for efficient wiring. Mounting type is through-hole providing strong mechanical and electrical connection to PCBs.
Series is Mini-Match, known for compact design and reliable performance in board-to-board connections. Contact material is brass plated with tin over nickel for durability and conductivity. Operating temperature range is from -40°C to 85°C accommodating harsh environments.
Housing material is Polyethylene Terephthalate ensuring electrical insulation and durability.
The product is manufactured in India and complies with relevant industrial standards. It is ideal for use in industrial, manufacturing, electronics assembly, and research laboratory environments requiring compact and reliable connector solutions.
Explore more PCB connectors and IDC Connector variants in the Electronics & Electricals category at EnvMart for your specific project requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This IDC connector has a current rating of 7A.
It can handle voltages of 250V to 300V AC.
The pitch of this connector is 2.5mm.
The operating temperature range is from -40°C to 85°C.
It uses insulation displacement contact (IDC) termination type.
This connector features 5 contacts arranged in a single row.
The housing is made from Polyethylene Terephthalate, and the contacts are brass plated with tin over nickel.
This model is designed for through-hole mounting.
The connector is rated for operation in temperatures ranging from -40°C to 85°C, making it suitable for various climates, including outdoor applications.
It is commonly used in desktop computers, home entertainment systems, remote controls, and measuring devices.
The connector features a straight orientation with an unshrouded design.
This connector is manufactured in India.
