Nexperia 9.1 V Zener Diode Single 500 mW Voltage Regulator 2-Pin SOD-80 BZV55-C9V1,115

Nexperia BZV55-C9V1,115 is a high-quality 9.1 V Zener Diode designed for voltage regulation in electronic circuits. This single element diode comes in a compact 2-pin SOD-80 surface mount package, with a maximum power dissipation of 500 mW, making it suitable for a variety of applications requiring stable voltage references.

The device features a nominal zener voltage (Vz) of 9.1 V with a tolerance of ±5%, a maximum reverse leakage current of 500 nA, and a typical voltage temperature coefficient of 5.5 mV/°C, ensuring dependable operation under varying thermal conditions. Its operating temperature range extends from -65°C up to 200°C, supporting use in demanding industrial and commercial environments.

The BZV55 series is optimized for surface mounting, allowing for efficient PCB space utilization and automated assembly processes. Its low zener impedance of 15 Ω and test current of 5 mA provide tight voltage regulation important for sensitive electronics.

This Zener Diode is widely used in power supply circuits, voltage reference circuits, and protection circuits across industrial electronics, communication equipment, and consumer devices.

Nominal 9.1 V voltage regulator diode. Surface mount 2-pin SOD-80 package. 500 mW max power dissipation. Low leakage current and stable operation. Wide temperature range from -65°C to 200°C. Tight voltage tolerance of ±5% for precision applications.

Typical voltage temperature coefficient: 5.5 mV/°C. Explore our broad range of semiconductor components for your industrial, laboratory, manufacturing, and electronic design needs on EnvMart.
