Wurth Elektronik Shielded Wirewound Surface Mount Inductor 4.7 μH ±20% 4.6 A Idc WE-HCI Series 5040 744316470
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 4mm |
| Length | 5.3mm |
| Depth | 5.5mm |
| Packaging | Tape & Reel |
| Series | WE-HCI |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | WE-Perm2 |
| Inductance | 4.7μH |
| Standards/Approvals | IEC 61249-2-21, JEDEC JS709B, REACH, RoHS |
| Package/Case | 5040 |
| Maximum DC Current | 4.6A |
| Pin Count | 2 |
| Maximum DC Resistance | 24.5mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 57MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a magnetically shielded wirewound design for low stray fields.
- Includes a WE-Perm2 core material providing high performance in surface mount applications.
- Designed for industrial computers, laptops, graphic cards, motherboards, and power circuit filters.
- Features a 5040 package case sized 5.3mm x 5.5mm x 4mm (LxDxH) with 2 pins and tape & reel packaging.
- Meets AEC-Q200 automotive standard and complies with IEC 61249-2-21, JEDEC JS709B, REACH, and RoHS regulations.
- Operates reliably between -40°C and 150°C temperature range.
- Maximum DC resistance of 24.5 mΩ ensures low power dissipation.
- Maximum self-resonant frequency is 57 MHz, supporting high-frequency circuits.
Product Description
Wurth Elektronik 744316470 is a shielded wirewound Surface Mount Inductor featuring a WE-Perm2 core. It delivers a nominal inductance of 4.7 μH with a tolerance of ±20% and supports a maximum DC current of 4.6 A, making it suitable for demanding high-current applications.
This inductor utilizes a magnetically shielded wirewound construction that minimizes electromagnetic interference and stray magnetic fields. The 5040 package size (length 5.3 mm, depth 5.5 mm, height 4 mm) is optimized for compact surface mounting on PCBs.
Complying with the AEC-Q200 automotive standard and certifications including IEC 61249-2-21, JEDEC JS709B, REACH, and RoHS, this component is reliable for industrial and automotive environments. It performs efficiently across a wide temperature range from -40°C up to 150°C.
Common applications include industrial computers, laptops, graphic cards, motherboards, DC-DC converters, filters, high current switching regulators, and polyphase switching regulators where low DC resistance and high self-resonant frequency (up to 57 MHz) are crucial.
Magnetically shielded wirewound inductor construction. WE-Perm2 core material for stable inductance characteristics. Compact 5040 surface mount package with tape & reel packaging. Maximum DC resistance of 24.5 milliohms for improved efficiency.
Suitable for automotive standards and industrial applications. Operating temperature range from -40°C to 150°C. Maximum DC current rating of 4.6 amperes.
This inductor is manufactured in China and offered in tape and reel packaging for automated PCB assembly. It facilitates efficient power regulation and noise filtering in electronic circuits.
Explore more surface mount electronic components and inductors in the Electronics & Electricals category at EnvMart for industrial, automotive, and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal inductance of this model is 4.7 μH with a tolerance of ±20%.
It supports a maximum DC current of 4.6 A, making it suitable for high-current applications.
This inductor comes in a 5040 package size, measuring 5.3 mm in length, 5.5 mm in depth, and 4 mm in height.
The maximum operating temperature is 150°C, allowing it to function effectively in high-temperature environments.
It utilizes a WE-Perm2 core material, which provides stable inductance characteristics.
This model meets the AEC-Q200 automotive standard and complies with IEC 61249-2-21, JEDEC JS709B, REACH, and RoHS regulations.
The maximum self-resonant frequency is 57 MHz, supporting high-frequency circuit applications.
It is packaged in tape and reel format, which is suitable for automated PCB assembly.
The maximum DC resistance is 24.5 mΩ, which helps in reducing power dissipation.
This inductor features a wirewound construction, which is designed to minimize electromagnetic interference and stray magnetic fields.
It is suitable for applications in industrial computers, laptops, graphic cards, motherboards, and power circuit filters.
The minimum operating temperature is -40°C, allowing it to operate in low-temperature environments.
