Wurth Elektronik 5020 Shielded Surface Mount Inductor with Powdered Iron Core 680 nH ±20%, 6.8 A IDC 744373340068
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 1.8mm |
| Length | 5.2mm |
| Depth | 5.2mm |
| Packaging | Tape & Reel |
| Series | WE-LHMI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Powdered Iron |
| Inductance | 680nH |
| Standards/Approvals | RoHS, REACH, JEDEC JS709B, IEC 61249-2-21 |
| Package/Case | 5020 |
| Maximum DC Current | 6.8A |
| Pin Count | 2 |
| Maximum DC Resistance | 12.4mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 90MHz |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 5020 package size measuring 5.2mm length and depth, with 1.8mm height.
- Rated maximum DC current of 6.8 A for high current applications.
- Features low maximum DC resistance of 12.4 milliohms ensuring efficient power delivery.
- Operating temperature range from -40°C to 125°C suitable for harsh environments.
- Automotive grade with AEC-Q200 certification for reliability.
- Shielded construction minimizes electromagnetic interference.
- Packaging available in tape and reel format for automated assembly.
- Meets relevant standards including RoHS, REACH, JEDEC JS709B, and IEC 61249-2-21.
Product Description
Wurth Elektronik 744373340068 is a 5020 shielded surface mount inductor constructed with a powdered iron core and designed for compact, high-performance power circuitry.
This inductor features a nominal inductance of 680 nH with an inductance tolerance of ±20%, enabling precise filtering and energy storage in DC-DC converter circuits and other power supplies.
The device supports a maximum DC current of 6.8 A, making it suitable for high current transient spikes without acoustic noise or leakage fields. Its shielded construction reduces electromagnetic interference, protecting sensitive electronic components.
Physical dimensions are 5.2 mm in length and depth, with a height of 1.8 mm, fitting efficiently into space-constrained printed circuit boards. The inductor meets automotive standards with its AEC-Q200 qualification, ensuring reliability in demanding automotive and industrial applications.
Other specifications include a maximum DC resistance of 12.4 milliohms, an operating temperature range from -40°C to 125°C, and a high self-resonant frequency of 90 MHz, supporting high frequency operations.
The inductor is supplied in tape and reel packaging, facilitating automated assembly in manufacturing environments.
Typical applications include DC-DC converters for high current power supplies, POL converters, mainboards, graphic cards, battery-powered devices such as PDAs and digital cameras, and other portable power electronics.
Compact 5020 package with molded shielded construction for EMI reduction. High current rating of 6.8 A for transient spike handling. Wide operating temperature range suitable for automotive use. Low DC resistance to maximize efficiency.
Compliant with multiple environmental and electrical standards including RoHS and REACH. Suitable for DC-DC and POL converter circuits in various electronics devices.
Explore more components like the Wurth Elektronik WE-LHMI series inductors in the Surface Mount Inductor category at EnvMart for your industrial and commercial electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal inductance of this inductor is 680 nH with an inductance tolerance of ±20%.
It supports a maximum DC current of 6.8 A, making it suitable for high current applications.
This unit measures 5.2 mm in length and depth, with a height of 1.8 mm.
The operating temperature range is from -40°C to 125°C, suitable for harsh environments.
The maximum DC resistance is 12.4 milliohms, ensuring efficient power delivery.
The shielded construction minimizes electromagnetic interference, protecting sensitive electronic components.
It is available in tape and reel packaging, facilitating automated assembly.
This model is AEC-Q200 certified, ensuring reliability in automotive applications.
The maximum self-resonant frequency is 90 MHz, supporting high frequency operations.
The core material is powdered iron, which contributes to its performance characteristics.
It complies with RoHS, REACH, JEDEC JS709B, and IEC 61249-2-21 standards.
Typical applications include DC-DC converters, POL converters, and various portable power electronics.
