onsemi DC Input Optocoupler Through Hole 6-Pin DIP with FET Output 1.75V Forward Voltage H11F1TVM
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Model | H11F1TVM |
| Packaging | Tape & Reel |
| Mount Type | Through Hole |
| Output type | FET |
| Series | H11F |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 60mA |
| Number Of Channels | 1 |
| Standards/Approvals | IEC60747-5-2, UL |
| Maximum Forward Voltage | 1.75V |
| Number of Pins | 6 |
| Input Current Type | DC |
| Typical Rise Time | 45μs |
Key Features
- Designed for distortion-free control of low-level AC and DC analogue signals.
- Features a maximum forward voltage of 1.75V and typical rise time of 45 microseconds.
- Supports a maximum input current of 60mA and has a single channel configuration.
- Operates within a temperature range of -40°C to 100°C ensuring durability.
- Complies with IEC60747-5-2 and UL standards for safety and performance.
- Available in Tape & Reel packaging suitable for automated manufacturing processes.
- Package type is Dual Inline Package (DIP) with 6 pins for through-hole mounting.
- Non-automotive grade component, part of the H11F series.
Product Description
onsemi H11F1TVM DC Input Optocoupler features a 6-pin DIP Through Hole package designed for industrial and electronic applications requiring true isolation and analogue signal control. The device internally isolates the photo-detector from the infrared emitting diode to provide a distortion-free FET output suitable for low-level AC and DC analogue signals.
This optocoupler offers a maximum forward voltage of 1.75V, ensuring efficient operation with low power dissipation. It supports a maximum input current of 60mA and provides a typical rise and fall time of 45 microseconds, making it suitable for fast signal response needs.
The single-channel device operates reliably over a wide temperature range from -40°C to 100°C and meets recognized standards such as IEC60747-5-2 and UL, assuring compliance with safety and quality requirements. The H11F series device is not rated for automotive use but excels in industrial, laboratory, and manufacturing settings.
The component is shipped in Tape & Reel packaging, compatible with automated insertion processes to enhance production efficiency. Its through-hole DIP package with 6 pins ensures robust mechanical mounting and electrical connectivity.
Distortion-free analogue FET output for precise control. Wide operating temperature range from -40°C to 100°C. Complies with IEC60747-5-2 and UL standards. 6-pin DIP Through Hole mount for secure installation. Supplied in Tape & Reel packaging for manufacturing convenience.
Typical rise and fall times of 45 microseconds for fast response. Maximum input current of 60mA supports a range of applications. Single-channel device designed for industrial and electronic components.
This optocoupler is ideal for use in industrial automation, electronic instrumentation, signal isolation, and various analogue signal interfacing applications. It provides reliable electrical isolation to protect sensitive circuits and enables the safe transmission of signals in noisy environments.
Explore other Optocoupler and photodetector solutions at EnvMart to find compatible components and accessories for your industrial and electronic systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input current for the H11F1TVM is 60mA.
This model has a typical rise time of 45 microseconds.
It operates within a temperature range of -40°C to 100°C.
The output type of this optocoupler is FET.
This optocoupler features a 6-pin configuration.
It complies with IEC60747-5-2 and UL standards.
The maximum forward voltage is 1.75V.
The package type is Dual Inline Package (DIP).
It is designed for through-hole mounting.
It is supplied in Tape & Reel packaging, suitable for automated manufacturing processes.
This optocoupler is suitable for industrial automation, electronic instrumentation, and signal isolation applications.
This model has a single channel configuration.
