onsemi PLL Frequency Multiplier 1 Output Surface Mount 16-Pin TSSOP 3.63V NB3N3020DTG

Free Delivery in India | Lowest Global Shipping Charges

onsemi PLL Frequency Multiplier 1 Output Surface Mount 16-Pin TSSOP 3.63V NB3N3020DTG

Name: onsemi PLL Frequency Multiplier 1 Output Surface Mount 16-Pin TSSOP 3.63V NB3N3020DTG
Brand: onsemi
SKU: 132364
Price: 11.72 USD
Availability: InStock



Category Clock Synthesizers Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.05mm
Length	5.1mm
Model	NB3N3020DTG
Width	4.5mm
Mount Type	Surface
Series	NB3N3020
Maximum Operating Temperature	85°C
Package Type	TSSOP
Sub Type	Multipliers/Dividers
Minimum Operating Temperature	-40°C
Number of outputs	1
Maximum Output Frequency	210MHz
Pin Count	16
Maximum Supply Voltage	3.63V
Minimum Supply Voltage	2.97V
Output Logic Level	CMOS

Key Features

The device supports maximum input and output frequencies of 210MHz ensuring high speed signal processing.
Surface mount mount type facilitates easy PCB assembly and compact design.
Minimum operating temperature of -40°C and maximum up to 85°C allows operation across industrial temperature ranges.
Package dimensions include a length of 5.1 mm, width of 4.5 mm, and height of 1.05 mm for precise mechanical integration.
The product is part of the NB3N3020 series and does not comply with automotive standards.
Output logic leverages CMOS technology suitable for modern digital systems.
Single output configuration simplifies integration in frequency multiplier designs.
Low voltage supply range from 2.97V minimum to 3.63V maximum optimizes power consumption.

Product Description

onsemi NB3N3020DTG PLL Frequency Multiplier is a precision electronic component designed for high-frequency clock generation and timing applications in industrial, laboratory, and manufacturing environments. This surface mount device features a compact 16-pin TSSOP package suitable for automated insertion into printed circuit boards, ensuring space-efficient and reliable signal multiplication.

The device operates within a supply voltage range of 2.97V to 3.63V and supports maximum input and output frequencies up to 210MHz, making it applicable in systems requiring precise frequency synthesis and timing control. The CMOS output logic level provides compatibility with contemporary digital electronics components.

Engineered to perform across extended temperature ranges from -40°C to 85°C, the NB3N3020DTG is suitable for robust industrial environments. Its physical dimensions (length 5.1 mm, width 4.5 mm, height 1.05 mm) allow integration into compact electronics designs without sacrificing performance.

This clock generator does not carry automotive standards, indicating its primary use in non-automotive electronics sectors. Applications include frequency synthesis in communications equipment, test instrumentation, and digital timing systems.

The device features a single output line to provide multiplied clock frequencies. Compact TSSOP packaging facilitates efficient surface mount technology assembly. Supports industrial temperature range ensuring operational reliability.

Supply voltage range tailored for low power consumption use cases. CMOS output logic level ensures compatibility with standard digital circuits. 16-pin configuration provides stable electrical connections and signal integrity.

Designed for high frequency multipliers and dividers in electronic systems. Ideal for electronics manufacturing, research labs, and measurement equipment.

EnvMart customers in electronics manufacturing, laboratory instrumentation, and industrial automation sectors will find this onsemi PLL Frequency Multiplier suitable for their precision frequency generation needs. Explore more semiconductor and clock synthesizer products on EnvMart to complement your electronic design requirements.

Explore more products in our Clock Synthesizers category.
