TDK ERU20 Shielded Wirewound Surface Mount Inductor with Ferrite Core 4.7 μH ±10%, 22 A Idc B82559A
Specifications
| Country of Origin | China |
|---|---|
| Brand | TDK |
| Height | 9.8mm |
| Length | 21.5mm |
| Model | ERU20 |
| Depth | 21mm |
| Packaging | Tape & Reel |
| Series | B82559A |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 4.7μH |
| Standards/Approvals | RoHS |
| Package/Case | ERU20 |
| Maximum DC Current | 22A |
| Maximum DC Resistance | 2.6mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a ferrite core for efficient magnetic performance.
- Features magnetic shielding for reduced electromagnetic interference.
- Compliance with AEC-Q200 automotive standard ensures high reliability.
- Surface mount termination style enables easy PCB mounting.
- Rated for operation from -40°C to 150°C for wide temperature resilience.
- Low maximum DC resistance of 2.6 mΩ contributes to efficiency.
- Supplied in tape & reel packaging suitable for automated assembly.
- Maximum self-resonant frequency up to 2 MHz supports high-frequency applications.
Product Description
TDK ERU20 Shielded Wirewound Surface Mount Inductor (Model B82559A) offers precise inductance of 4.7 μH ±10% and is designed for high current handling up to 22 A DC. This inductor utilizes a ferrite core with magnetic shielding to minimize electromagnetic interference, ensuring stable performance in sensitive electronic circuits.
Its construction features helically wound wire on a ferrite core with surface mount termination style, facilitating compact and secure attachment to PCBs. The component complies with the demanding AEC-Q200 automotive standard, making it suitable for automotive and industrial electronics.
The device operates reliably within a temperature range from -40°C to 150°C, accommodating various environmental conditions. Low DC resistance of 2.6 mΩ enhances power efficiency and reduces energy losses during operation.
Dimensions measure 21.5 mm in length, 9.8 mm in height, and 21 mm in depth, enabling efficient space utilization in circuit design. The maximum self-resonant frequency of 2 MHz supports high-speed electronics applications such as DC-DC converters, POL converters, VRM modules, and solar converters.
Ferrite core for efficient magnetic properties. Magnetically shielded construction to reduce EMI. Surface mount design simplifies PCB integration. AEC-Q200 certified for automotive reliability. Temperature rating from -40°C to 150°C ensures durability.
Low DC resistance (2.6 mΩ) for enhanced efficiency. Compact size fits constrained PCB layouts.
This wirewound inductor is ideal for applications in industrial, automotive, and power electronics sectors where high current and precision inductance are required. It is supplied in tape & reel packaging compatible with automated production processes. Explore more surface mount inductors and Electronic Components in the EnvMart catalog for your advanced electronics design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TDK ERU20 Shielded Wirewound Surface Mount Inductor has an inductance value of 4.7 μH ±10%.
This inductor is rated for a maximum DC current of 22 A.
The dimensions of this model are 21.5 mm in length, 9.8 mm in height, and 21 mm in depth.
It operates reliably within a temperature range from -40°C to 150°C.
The inductor utilizes a ferrite core for efficient magnetic performance.
The maximum self-resonant frequency of this inductor is up to 2 MHz.
This model features a surface mount termination style, which facilitates easy PCB mounting.
The maximum DC resistance is 2.6 mΩ, contributing to its efficiency.
Yes, it complies with the AEC-Q200 automotive standard, ensuring high reliability for automotive applications.
It is supplied in tape & reel packaging, which is suitable for automated assembly processes.
This wirewound inductor is ideal for applications in industrial, automotive, and power electronics sectors where high current and precision inductance are required.
The inductor complies with RoHS standards, ensuring it meets environmental regulations.
