Wurth Elektronik WE-MAPI 3015 Wirewound Surface Mount Inductor 6.8 μH ±20% Moulded Composite Iron Powder Core 74438335068
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | Wurth Elektronik |
| Height | 1.5mm |
| Length | 3mm |
| Depth | 3mm |
| Packaging | Tape & Reel |
| Series | WE-MAPI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Composite Iron Powder |
| Inductance | 6.8μH |
| Standards/Approvals | IPC/JEDEC J-STD-020D |
| Package/Case | 3015 |
| Maximum DC Current | 1.1A |
| Maximum DC Resistance | 287mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 25MHz |
| Inductor Construction | Moulded |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 3015 package size measuring 3mm x 3mm x 1.5mm.
- Designed for high transient current handling with maximum DC current of 1.1A.
- Moulded composite iron powder core provides magnetic shielding.
- Operates reliably within -40°C to 125°C temperature range.
- Surface mount termination suitable for automated PCB assembly.
- Meets IPC/JEDEC J-STD-020D and automotive AEC-Q200 standards.
- Low maximum DC resistance of 287mΩ minimizes power loss.
- High maximum self-resonant frequency of 25 MHz for good high frequency performance.
Product Description
Wurth Elektronik 74438335068 WE-MAPI series is a wirewound surface mount inductor with a composite iron powder core, offering 6.8 μH inductance with a tolerance of ±20%. This moulded inductor is designed to provide high current capacity and excellent transient current handling capabilities, suitable for demanding electronic applications.
The 3015 package dimensions (3mm length, 3mm depth, and 1.5mm height) make it compact and ideal for high-density PCB layouts in mobile devices and power supplies. The composite iron powder core construction enhances magnetic shielding, reducing leakage flux and acoustic noise during operation.
Operating temperature range from -40°C to 125°C ensures robustness in harsh automotive and industrial environments. Its maximum DC current rating of 1.1A and DC resistance of 287 milliohms supports efficient power delivery with minimized losses. The inductor also features a maximum self-resonant frequency of 25 MHz, suitable for high-frequency power conversion circuits.
This Wurth Elektronik inductor conforms to IPC/JEDEC J-STD-020D and the automotive AEC-Q200 standards, ensuring reliability and quality for automotive and industrial applications. The surface mount termination style allows for easy automated assembly and improved production efficiency.
Applications include DC/DC converters for high current power supplies, FPGA power regulation, POL converters, portable electronics such as digital cameras and PDAs, as well as wireless communication devices. This makes it an essential component in modern electronics demanding stable power management in compact form factors.
Compact 3015 size suitable for dense PCB layouts. Composite iron powder core for magnetic shielding and noise reduction. High transient current spike tolerance for rugged performance. Wide operating temperature range from -40°C to 125°C.
Low DC resistance of 287 milliohms for energy efficiency. Certified to automotive and IPC/JEDEC standards. Explore more Wurth Elektronik components and Surface Mount Inductors on EnvMart to enhance your electronics projects with premium quality parts.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 6.8 μH with a tolerance of ±20%.
The inductor has a compact package size of 3mm in length, 3mm in depth, and 1.5mm in height.
It has a maximum DC current rating of 1.1A, allowing it to handle high transient currents effectively.
The maximum self-resonant frequency is 25 MHz, which supports high-frequency performance.
This unit operates reliably within a temperature range of -40°C to 125°C.
It features a composite iron powder core, which enhances magnetic shielding and reduces noise.
It meets IPC/JEDEC J-STD-020D and automotive AEC-Q200 standards, ensuring quality and reliability.
The maximum DC resistance is 287 mΩ, which helps minimize power loss during operation.
It uses a surface mount termination style, suitable for automated PCB assembly.
The inductor is packaged in tape and reel format, facilitating easy handling and assembly.
It is suitable for applications such as DC/DC converters, FPGA power regulation, and portable electronics.
This inductor is moulded, which contributes to its compact design and performance characteristics.
