Eaton Non-Resettable Radial Fuse 5A 250V AC Time Delay SR-5-5A-BK
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V ac |
| Diameter | 8.5mm |
| Brand | Eaton |
| Height | 7.6mm |
| Length | 7.37mm |
| Model | SR-5-5A-BK |
| Width | 8.5mm |
| Current Rating | 5A |
| Series | SR5 |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Lead Length | 4.3mm |
| Breaking Capacity | 50A |
| Lead Diameter | 1mm |
| Fuse Characteristics | Time Delay |
| Lead Orientation | Radial |
Key Features
- This fuse features radial lead orientation for easy PCB mounting.
- Rated current of 5 amperes and voltage of 250 volts AC.
- Time delay fuse characteristic allows high inrush currents without blowing.
- Compact dimensions include length 7.37mm, width 8.5mm, and height 7.6mm.
- Operating temperature range from -40°C minimum to 85°C maximum.
- Breaking capacity is 50 amperes to ensure safe circuit interruption.
- Fuse body constructed of thermoplastic polyamide for durability.
- Lead diameter measures 1mm and lead length 4.3mm for secure connection.
Product Description
Eaton SR-5-5A-BK is a non-resettable radial fuse designed for overcurrent protection in various electronic and electrical applications. This fuse operates at a current rating of 5A and voltage rating of 250V AC, featuring time delay characteristics which provide high inrush current capability without nuisance blowing.
The radial lead orientation and compact size make it well-suited for PCB mounting and integration into electronic circuitry. Dimensions are precise with a length of 7.37mm, width of 8.5mm, height of 7.6mm, lead length of 4.3mm, and lead diameter of 1mm. The body is constructed from thermoplastic polyamide ensuring durability and safety under various operating conditions.
Operating temperature range from -40°C to 85°C and a breaking capacity of 50A ensure robust performance in demanding environments. This fuse is compliant with internationally recognized standards such as IEC 60068-2-20, VDE, PSE, IEC 60127-3, and RoHS directives, reinforcing its suitability for reliable circuit protection.
Eaton SR-5 series fuses are widely accepted for both primary and secondary overcurrent protection in industrial, laboratory, manufacturing, electronics, electrical, automotive, and commercial sectors. They provide dependable safety for critical electronic components and systems.
This fuse features radial lead orientation for easy PCB mounting. Rated current of 5 amperes and voltage of 250 volts AC. Time delay fuse characteristic allows high inrush currents without blowing. Compact dimensions include length 7.37mm, width 8.5mm, and height 7.6mm.
Operating temperature range from -40°C minimum to 85°C maximum. Breaking capacity is 50 amperes to ensure safe circuit interruption. Fuse body constructed of thermoplastic polyamide for durability. Lead diameter measures 1mm and lead length 4.3mm for secure connection.
Complies with IEC 60068-2-20, VDE, PSE, IEC 60127-3, and RoHS standards. Ideal for primary and secondary overcurrent protection in electronic equipment. Explore Eaton products and similar Fuse solutions on EnvMart for reliable circuit protection components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 5 amperes and a voltage rating of 250 volts AC.
The breaking capacity of this fuse is 50 amperes, ensuring safe circuit interruption.
The dimensions are length 7.37mm, width 8.5mm, and height 7.6mm.
It features a radial lead orientation, making it suitable for easy PCB mounting.
The operating temperature range is from -40°C to 85°C.
The fuse body is constructed from thermoplastic polyamide, ensuring durability.
This fuse has a time delay characteristic, allowing it to handle high inrush currents without blowing.
It complies with IEC 60068-2-20, VDE, PSE, IEC 60127-3, and RoHS directives.
The lead diameter measures 1mm, and the lead length is 4.3mm.
This fuse is suitable for primary and secondary overcurrent protection in various sectors including industrial, automotive, and electronics.
This model belongs to the Eaton SR5 series of fuses.
The time delay characteristic allows the fuse to tolerate temporary overcurrents, preventing nuisance blowing during high inrush conditions.
