TE Connectivity SDL Series Shielded Straight 1 Port 4 Way SDL Connector 520461-1

TE Connectivity 520461-1 SDL Connector is a shielded straight connector with 1 port and 4 ways, engineered to provide superior EMI/RFI protection for numerous industrial and commercial applications. It features a shell-type design with a compact footprint measuring 25.27 mm in length, 8.74 mm in width, and 6.68 mm in depth, making it suitable for high-density electronic systems.

This SDL (Shielded Data Link) connector belongs to the 50 series round cable IDC plug connectors, optimized for use with round shielded 7 stranded cables. The connector includes pre-loaded insulation displacement contacts spaced on a 1.27 mm centreline, ensuring reliable signal integrity and connection stability.

The housing incorporates locking latches and positive polarization features for secure mating. Additionally, it offers primary strain relief applied to the cable foil or shield, along with secondary strain relief for the main cable conductors to prevent mechanical stress damage.

Note that the top and bottom shielding shells and ferrules for SDL IDC plug connectors are sold separately, including top shield (stock number 717-4423), bottom shield (stock number 717-4426), and ferrule (stock number 717-4432). Bundles exist for different wire gauges and port counts, but this specific model supports 1 port and 4 ways, designed for 24 AWG wire.

This connector does not carry hazardous area certifications or specific standards/approvals but meets industry demands for cost-effective and reliable shielded connectors. Designed for shielded applications offering EMI/RFI protection.

Features a straight orientation with a shell-type connector. Includes 1 port and 4-way connections for versatility. Compact dimensions with length of 25.27 mm, width of 8.74 mm, and depth of 6.68 mm. Constructed for use with 50 series round cables and IDC plug connectors.

Suitable for medical systems, point-of-sale equipment, computers, and video games. Housing incorporates locking latches with positive polarization for secure connections. Provides primary and secondary strain relief for cable durability.

Meets industry demand for cost-effective shielded connector solutions.

Ideal for industrial, medical, commercial, and communication system integrations requiring dependable shielded connectors. Explore more Ethernet Connectors and related components at EnvMart for comprehensive solutions.
