Samtec PCB Socket Straight Through Hole 50-Contact 2 Row 2.54 mm Pitch 7.1A 550V Polyester Housing SLW-125-01-G-D

Samtec SLW-125-01-G-D is a high-quality straight through hole PCB socket designed for board-to-board electrical connections. It features 50 female contacts arranged in 2 rows with a 2.54 mm pitch, optimized for secure and reliable solder mount applications.

The socket housing is constructed from black glass-filled polyester, offering excellent mechanical strength and electrical insulation. The contacts inside use a phosphor bronze base material with a 0.51μm gold plating, providing superior conductivity and resistance against corrosion over extended use.

Rated for a current of 7.1 Amps and supporting voltages up to 550 Volts, this socket is suited for demanding industrial and electronic applications including PCB assemblies in telecommunications, computing, and industrial equipment.

The low profile design with a stacking height of 10 mm and a 3.25 mm solder tail facilitates compact and efficient PCB layouts, reducing space without sacrificing performance. It operates reliably in a wide temperature range from -55°C up to 125°C, making it suitable for varied climatic conditions and industrial environments.

This SLW series socket mates with TLW, TSM, and TSW series low profile square post headers, allowing for versatile board-to-board configurations in manufacturing and prototyping setups.

Applications include use in industrial control systems, telecommunications hardware, computing equipment, and other electronic assemblies requiring secure and durable electrical connections.

The housing is made from durable black glass-filled polyester providing excellent insulation. The 7.1 Amp rated socket supports up to 550V for reliable electrical performance. Contacts are made of phosphor bronze with 0.51μm gold plating ensuring high conductivity and corrosion resistance.

The low profile design includes a 10mm stacking height and a 3.25mm solder tail for mounting. Operating temperature range is from -55°C to +125°C suitable for harsh environments. This socket system mates with compatible TLW, TSM, and TSW series headers for flexible assembly.

Termination type is solder, optimized for through-hole mounting on PCB. Connector gender is female with tiger buy contacts providing secure connections. No specific standards or approvals are listed for this product. For more advanced PCB connector solutions, explore further browsing within the Electronics & Electricals category at EnvMart.
