DiodesZetex Surface Mount Positive Voltage Regulator 6V 3-Pin AP7333-33SRG-7
Specifications
| Country of Origin | China |
|---|---|
| Voltage | Regulators DiodesZetex, Voltage Regulator 6V 3-Pin RS Stock No |
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 3mm |
| Model | AP7333-33SRG-7 |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | AP7333 |
| Maximum Operating Temperature | 85°C |
| Polarity | Positive |
| Maximum Input Voltage | 6V |
| Quiescent Current | 85μA |
| Minimum Input Voltage | 2V |
| Pin Count | 3 |
Key Features
- This LDO (Low Dropout) regulator operates with a low input-output differential voltage.
- It features a quiescent current of 85μA for efficient power consumption.
- The device has a compact form factor with dimensions 3mm length, 1.4mm width, and 1mm height.
- Designed to handle a maximum input voltage of 6V and operate safely up to 85°C.
- Surface mount design allows for easy PCB integration in various electronic devices.
- It offers fast transient response and low noise performance with high Power Supply Rejection Ratio (PSRR).
- Suitable for a wide input voltage range from 2V minimum to 6V maximum input.
- Polarity is positive, ideal for standard voltage regulator configurations.
Product Description
DiodesZetex AP7333-33SRG-7 is a surface mount voltage regulator designed for effective power management in electronic devices requiring a regulated 3.3V output at low dropout voltages. This 3-pin positive polarity regulator boasts a quiescent current of just 85μA, ensuring low power consumption during operation. It supports a wide input voltage range from 2V to 6V and can operate safely in environments up to 85°C, making it suitable for various industrial, consumer electronics, and embedded system applications.
The compact physical dimensions (3mm x 1.4mm x 1mm) facilitate PCB space optimization and enhanced circuit layouts. Its low dropout linear regulator design provides fast transient response and low noise operation, delivering highly stable voltage output with excellent Power Supply Rejection Ratio (PSRR). This feature minimizes the impact of fluctuations in the input voltage, ensuring reliability in sensitive circuitry.
The regulator is surface mountable, easing automated placement and soldering processes on printed circuit boards, greatly improving production efficiency in volume manufacturing contexts. It is ideal for use in power management IC arrays, portable devices, and embedded electronic systems that need consistent voltage levels.
The product is manufactured in China and does not carry any automotive-specific standards, but it meets the required specs for general electronics and power regulators. It is a component well-suited for industrial electronics, power supply units, embedded systems development, and other electronics manufacturing applications.
Low dropout linear voltage regulator with 3.3V output voltage. Low quiescent current of 85μA for energy-efficient operation. Wide input voltage range of 2V to 6V suitable for various power sources. Compact surface mount package with 3 pins for easy PCB integration.
Maximum operating temperature of 85°C supports moderate environment conditions. Positive voltage polarity regulation for standard linear regulator applications. Fast transient response and low noise with high Power Supply Rejection Ratio (PSRR).
Designed primarily for industrial, manufacturing, and embedded electronics use. Manufactured in China ensuring consistent component quality. Explore more Voltage Regulator solutions and browse our comprehensive electronics components catalog on EnvMart for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a regulated output voltage of 3.3V.
The maximum input voltage it can handle is 6V.
It features a low quiescent current of 85μA, which contributes to energy-efficient operation.
The dimensions are 3mm in length, 1.4mm in width, and 1mm in height.
This unit can operate safely at temperatures up to 85°C.
The minimum input voltage supported is 2V.
It features a surface mount design, allowing for easy integration onto PCBs.
This model has a positive polarity, suitable for standard voltage regulator configurations.
It is designed for use in industrial electronics, power supply units, and embedded systems that require consistent voltage levels.
It provides fast transient response and low noise operation with a high Power Supply Rejection Ratio (PSRR).
This voltage regulator has a total of 3 pins.
The product is manufactured in China.
