onsemi Bridge Rectifier 400 V 50 A 4-Pin Single SDIP Surface Mount DF04S
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.6mm |
| Length | 8.51mm |
| Model | DF04S |
| Width | 6.5mm |
| Mount Type | Surface |
| Series | DF-S |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | SDIP |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Forward Current If | 1.5A |
| Peak Forward Voltage Vf | 1.1V |
Key Features
- Features low DC reverse current and glass passivated chip junction.
- Supports a peak reverse repetitive voltage of 400 V for robust operation.
- Maximum operating temperature up to 150°C ensures durability.
- Compact SDIP package with dimensions 8.51 mm length, 6.5 mm width, and 2.6 mm height.
- Configured as a single phase bridge rectifier with a forward current rating of 1.5 A.
- Peak non-repetitive forward surge current of 50 A for transient surge handling.
- Forward voltage drop is low at 1.1 V, improving efficiency.
- Pin count of 4 suitable for PCB surface mounting applications.
Product Description
onsemi DF04S Bridge Rectifier is a high-performance discrete semiconductor designed for electronic power rectification in industrial and electronic applications. This 400 V, 50 A bridge rectifier features a 4-pin SDIP surface mount package enabling compact and efficient PCB assembly.
The device incorporates a glass passivated chip junction that ensures low DC reverse current and improved reliability. It supports a peak reverse repetitive voltage (Vrrm) rating of 400 V, suitable for handling substantial voltage stresses during power conversion.
Thermally robust, the DF04S operates reliably in a temperature range from -55°C to 150°C, making it suitable for demanding environmental conditions in industrial, automotive (non-automotive standard), and consumer electronics scenarios. Its forward current rating is 1.5 A continuous with a peak non-repetitive forward surge current of 50 A to accommodate transient overloads.
Physical package dimensions include a length of 8.51 mm, a width of 6.5 mm, and a height of 2.6 mm, allowing for PCB surface mounting in designs requiring compact spatial footprints. The forward voltage drop is a low 1.1 V, optimizing power efficiency.
Low DC reverse current thanks to glass passivated junction. Peak reverse voltage of 400 V ensures capability for high voltage circuits. Peak forward surge current up to 50 A for transient overloads. Operating temperature range from -55°C to 150°C ensures wide application scope.
Standard UL certifications provide validated reliability. Compact SDIP package suitable for surface mount technology (SMT). Single-phase configuration for basic power rectification applications. 4-pin count for easy PCB integration and soldering.
Reliable performance in industrial, laboratory, electronic manufacturing and power supply design. Ideal for use in rectification of AC to DC conversion circuits.
This onsemi DF04S Bridge Rectifier is typically employed in semiconductor power components selections for electronic assemblies, power supplies, motor controls, and industrial automation systems.
Browse more semiconductor rectifiers and electronic components at EnvMart for compatible industrial-grade parts.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The DF04S bridge rectifier supports a peak reverse repetitive voltage of 400 V, making it suitable for high voltage applications.
This model has a maximum operating temperature of 150°C, allowing it to function reliably in demanding environments.
The physical dimensions of this bridge rectifier are 8.51 mm in length, 6.5 mm in width, and 2.6 mm in height.
The DF04S has a forward current rating of 1.5 A for continuous operation.
This bridge rectifier can handle a peak non-repetitive forward surge current of 50 A, accommodating transient overloads.
It is packaged in a compact SDIP (Surface Mount Device) format, suitable for PCB surface mounting applications.
The forward voltage drop for the DF04S is low at 1.1 V, which helps improve power efficiency.
This model operates reliably at temperatures as low as -55°C, allowing for use in various environmental conditions.
The DF04S features a pin count of 4, facilitating easy integration into PCB designs.
It is configured as a single-phase bridge rectifier, suitable for basic power rectification applications.
The peak reverse current for this bridge rectifier is 500 μA, which contributes to its low DC reverse current characteristics.
This bridge rectifier is typically employed in power supplies, motor controls, and industrial automation systems.
