Panasonic PhotoMOS AQY Series Solid State Relay, PCB Mount, 0.12 A Load, 40 V Load Voltage, 5 V dc Control AQY221N2M

Panasonic AQY221N2M PhotoMOS AQY Series Solid State Relay is designed for precision control of low-level analog signals in demanding electronic and industrial environments. This relay supports a maximum load current of 0.12 A and a maximum load voltage of 40 V, making it suitable for PCB mount applications requiring small, reliable switching solutions.

The device operates with a control voltage ranging from 1.5 V dc to 5 V dc, allowing efficient operation with low power signals. Its single pole single throw (SPST) contact configuration using MOSFET output technology provides low on-state resistance of just 23.5 ohms and minimal off-state leakage current of 0.01 μA, ensuring minimal signal distortion and excellent switching performance.

Encased in a compact SOP-4 package with PCB terminal mounting, the relay measures just 2.2 mm in length, 3 mm in width, and 1.4 mm in height, enabling easy integration into dense electronic assemblies.

Panasonic PhotoMOS relays are RoHS compliant and come with UL and cUL approvals, demonstrating adherence to international safety and quality standards. These relays are ideal for various applications including industrial automation systems, signal conditioning, control circuits, and other PCB-based electronic devices.

Operating temperature ranges from -40°C to 85°C, making AQY221N2M suitable for harsh environmental conditions encountered in manufacturing, laboratory, and industrial instrumentation.

Supports maximum load current of 0.12 amperes and maximum load voltage of 40 volts. Operates with a 5 V DC control voltage and low minimum of 1.5 V DC for control. Features low on-state resistance of 23.5 ohms and minimal off-state leakage current of 0.01 microamperes.

Compact SOP-4 packaging with PCB terminal type for optimized space utilization. Wide temperature tolerance from -40°C to 85°C ensures reliability under diverse conditions. RoHS compliant with UL, cUL approvals for safety and environmental standards.

Reliable MOSFET output and SPST contact configuration for precise switching in control applications.

This Panasonic PhotoMOS AQY Series Solid State Relay is an excellent choice for engineers seeking a high-quality, compact, and efficient SSR for industrial, laboratory, automotive, and electrical control applications. Explore more Solid State Relays in our Electronics & Electricals category at EnvMart.
