JST PH Series Right Angle Surface PCB Header Shrouded 8 Contacts 2 mm Pitch 1 Row S8B-PH-SM4-TB(LF)(SN)

JST S8B-PH-SM4-TB(LF)(SN) PH Series Right Angle Surface PCB Header is a high-density, compact wire-to-board connector designed for secure electrical connections in electronic assemblies. Featuring a shrouded, surface mount construction with 8 male contacts arranged in a single row with a 2 mm pitch, this header offers reliable performance within a voltage rating of 100V AC and a current rating of 2A.

The header utilizes copper alloy contacts plated with tin to ensure excellent electrical conductivity and resistance to corrosion. Its right angle orientation supports space-efficient PCB configurations, making it highly suitable for various electronics manufacturing, industrial equipment, and consumer electronics applications.

Engineered to operate reliably in temperature ranges from -25°C to 85°C, the connector ensures stable performance under diverse environmental conditions. The solder termination type facilitates solid mechanical and electrical connections to the PCB, while the fully shrouded design enhances protection against mechanical damage and prevents accidental contact with the pins.

Designed to accommodate wire gauges from 32 AWG to 24 AWG, this PH series header includes a dedicated PCB retention mechanism to enhance mounting security. While it does not carry specialized approvals, the connector is widely used in electronic circuits requiring dependable wire-to-board connectivity.

The header features a right angle orientation enabling compact PCB designs. It supports a current rating of 2A and voltage rating of 100V AC. Contact material is copper alloy with tin plating for durability and conductivity.

Designed for operation within temperature ranges from -25°C to 85°C. The connector uses solder termination type with a fully shrouded header for protection. It accommodates wire sizes from 32 AWG to 24 AWG, ideal for high-density PCB wiring.

The PH series header incorporates a printed circuit board retention mechanism for secure mounting. This component lacks formal standards or approval certifications but is suitable for general electronic applications.
