| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.05mm |
| Length | 1.8mm |
| Model | PMEG4010BEA,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | PMEG4010BEA |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 10A |
| Maximum Forward Voltage Vf | 640mV |
Nexperia PMEG4010BEA,115 is a Schottky barrier diode offered in a surface-mount 2-pin SOD-323 package designed for compact and high-efficiency electronic circuits.
Rated at 1 A continuous forward current and 40 V peak reverse voltage, this diode is optimized for low forward voltage drop (maximum 640 mV) and low leakage current, making it suitable for power management and protection applications.
The device meets AEC-Q101 automotive standard ensuring reliable operation under automotive and industrial conditions with a wide operating temperature range from -65°C to 150°C. Its ultra-small form factor with 1.8 mm length, 1.35 mm width, and 1.05 mm height facilitates space-saving printed circuit board layouts.
Key features include a fast response Schottky diode configuration, peak surge current handling of 10 A, and negligible power switching losses to improve system efficiency and thermal performance.
High efficiency with ultra-low forward voltage drop. Compact SOD-323 2-pin surface mount package. Wide operating temperature range from -65°C to 150°C. Automotive standard AEC-Q101 qualified. Low leakage current and fast switching performance.
Peak non-repetitive forward surge current of 10 A. Suitable for power rectification, voltage clamping and automotive electronics. Robust design for industrial and automotive electronics. Such a diode is widely used in industrial controls, power supplies, automotive electronics, and communication equipment.
