STMicroelectronics 600 V 1 A Switching Diode Through Hole DO-41 Package STTH1R06RL

STMicroelectronics STTH1R06RL is a reliable switching diode designed for electronic components and circuits requiring high voltage and current handling capabilities. Rated for a peak reverse repetitive voltage of 600 V and a maximum continuous forward current of 1 A, it is packaged in a compact DO-41 through hole format suitable for various power applications.

This diode has a single diode configuration optimized for switching tasks, characterized by a peak forward voltage of 1.7 V which aids in minimizing power losses. It features a low peak reverse current of 1 μA and a swift peak reverse recovery time of 45 ns, making it ideal for fast switching electronic circuits and power rectification.

Engineered to operate reliably in a broad temperature range from -65°C to 175°C, it is suitable for industrial, automotive, and commercial electronic applications exposed to harsh environments. The device supports a robust surge current of 25 A during transient conditions, ensuring durability under peak load stresses.

Its DO-41 package with dimensions of 5.2 mm length and 2.71 mm width/height facilitates easy installation on printed circuit boards through through-hole mounting. The device is free from specific standards or automotive certifications, but its design aligns well with general industrial electronic requirements.

This STTH1R06RL diode is commonly used in power supply circuits, voltage clamping, and signal switching in industries including manufacturing, industrial automation, and consumer electronics. It supports efficient energy management in circuits requiring fast and reliable switching performance.

Maximum continuous forward current of 1 ampere ensures reliable operation. Peak reverse repetitive voltage rating of 600 volts for high voltage applications. Single diode configuration optimized for switching applications.

Low peak reverse current of 1 microamp for efficient performance. Maximum forward voltage drop of 1.7 volts to reduce power dissipation. Wide operating temperature range from -65°C to 175°C for harsh environments. Fast peak reverse recovery time of 45 nanoseconds suitable for high speed switching.

Compact DO-41 package with 5.2 mm length and 2.71 mm diameter dimensions. Robust peak non-repetitive forward surge current rating of 25 amperes. Through hole mount type for easy PCB assembly. Explore more semiconductor components and discrete diodes at EnvMart for your industrial, laboratory, and commercial electronics needs.
