HARWIN M30 Series Straight Through Hole PCB Header, 6 Contacts, 1.25 mm Pitch, 1 Row, Shrouded M30-6100646
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 150V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 1A |
| Model | M30-6100646 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | M30 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.3mm |
Key Features
- The header is shrouded providing mechanical and electrical protection.
- It features a nylon housing that ensures durability and reliable insulation.
- The contact material is brass with tin plating for corrosion resistance and dependable electrical connectivity.
- This PCB header supports a rated current of 1 ampere and voltage up to 150 volts.
- The design includes a 2.3 mm tail pin length suitable for solder termination.
- Operating temperature ranges from -25°C to 85°C, allowing for diverse environmental applications.
- This male contact header is mounted through hole style for secure PCB attachment.
- It mates with M30-110 series housings and is ideal for wire-to-board connector systems.
Product Description
HARWIN M30-6100646 is a high-quality PCB header from the M30 series designed with a straight through hole configuration. It features 6 male contacts arranged in 1 row with a 1.25 mm pitch, suitable for precise wire-to-board connections in electronic assemblies.
The header housing is made of durable nylon material, ensuring excellent insulation and mechanical strength. Contacts are made from brass and plated with tin to provide corrosion resistance and excellent conductivity. This component supports a nominal current of 1 amp and withstands voltages up to 150 volts, making it suitable for various low-power electronic circuit applications.
With a tail pin length of 2.3 mm, this header is designed for solder termination through the PCB, ensuring stable and reliable mechanical and electrical connections. The shrouded design adds an extra layer of protection to contacts during installation and operation, reducing risk of damage or misalignment.
The operating temperature range from -25°C to 85°C enables use in a wide range of environments, including industrial, laboratory instrumentation, consumer electronic devices, and telecommunications equipment.
This PCB header is compatible with M30-110 series housings and is supplied in a tube packaging for efficient assembly line use. Its wire-to-board connector system type facilitates streamlined production workflows in manufacturing settings.
The header's shrouded structure ensures protection and durability. Brass contacts with tin plating provide reliable electrical performance. Nylon housing delivers strong insulation and mechanical stability. Designed for through hole mounting with solder termination type.
Rated for 1 amp current and 150 volts maximum voltage. Suitable for operating temperatures from -25°C to 85°C. Compatible with M30-110 series housings for connector integration. Ideal for industrial, electronic, and telecommunication applications.
Explore more high-quality PCB Headers and electronic components at EnvMart for diverse industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a rated current of 1 ampere and a maximum voltage of 150 volts.
It features a 1.25 mm pitch and has 6 male contacts arranged in 1 row.
The housing is made of nylon, while the contacts are brass with tin plating for corrosion resistance.
The tail pin length is 2.3 mm, designed for solder termination through the PCB.
It operates within a temperature range of -25°C to 85°C.
This model is designed for through hole mounting, ensuring secure attachment to the PCB.
It is designed for a wire-to-board connector system, facilitating efficient connections in electronic assemblies.
This PCB header is compatible with M30-110 series housings.
The orientation of this model is straight, suitable for direct connections in assemblies.
The shrouded design provides mechanical and electrical protection, reducing the risk of damage or misalignment during installation.
The country of origin for this PCB header is India.
It utilizes a solder termination type for secure connections to the PCB.
