XP Power AH DC/DC Converter, 200V DC Output, 7.5 mA, 5V DC Input, Through Hole Mount, 1.5 W, Operating -25°C to 75°C AH02P-5
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power AH DC/DC Converter, 200V dc/ 7 |
| Brand | XP Power |
| Length | 23.37mm |
| Model | AH02P-5 |
| Depth | 6.35mm |
| Gross Weight | 5.7g |
| Width | 11.43mm |
| Mount Type | Through Hole |
| Series | AH |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -25°C |
| MTBF | 1862000h |
| Number of outputs | 1 |
| Ripple and Noise | 3% Pk-Pk |
| Maximum Output Power | 1.5W |
| Maximum Input Voltage | 5V dc |
| Minimum Input Voltage | 0V dc |
| Output Voltage 1 | 200V dc |
| Output Current 1 | 7.5mA |
| Isolation Voltage | 500V |
Key Features
- Operates with a 5V DC input voltage range from 0V minimum up to 5V maximum.
- Through hole mount type offers sturdy installation in electronic assemblies.
- Features galvanic input-output isolation rated at 500V for safety and signal integrity.
- Suitable for operating temperatures between -25°C and 75°C for diverse environments.
- Low ripple and noise at 3% peak-to-peak ensure stable voltage output.
- Mean time between failures (MTBF) value is 1,862,000 hours indicating high reliability.
- Ideal for applications including avalanche photodiodes, capacitor charging, electrophoresis, photomultiplier tubes, piezo devices, and mass spectrometry.
- No external components required simplifying circuit design.
Product Description
XP Power AH02P-5 DC/DC Converter is an ultra miniature isolated DC to high voltage DC converter delivering 200V DC output at 7.5 mA current with a maximum power output of 1.5 W. It accepts a 5V DC input voltage range from 0V minimum to 5V maximum and is designed for through hole mounting, facilitating robust PCB assembly.
Constructed for reliable and efficient operation, the converter offers galvanic isolation between input and output rated at 500V, which helps maintain signal fidelity and safety. It provides a low ripple and noise level of 3% peak-to-peak, ensuring stable and clean output voltage essential in sensitive electronic applications.
Compact dimensions of 23.37mm in length, 11.43mm in width, and 6.35mm in depth, combined with a light weight of 5.7 grams, make it suitable for space-restricted applications. The device operates reliably across a wide temperature range from -25°C to 75°C, suitable for industrial and laboratory environments.
Benefits include a quasi-sinewave oscillator, input/output proportional control pin, low leakage current, and no minimum load requirement. It has a mean time between failures (MTBF) of 1,862,000 hours, reflecting high durability and dependable performance.
This converter is ideal for a variety of industrial uses such as avalanche photodiodes, capacitor charging, electrophoresis, photomultiplier tubes, piezoelectric devices, mass spectrometry, and sustaining ion pumps, supporting precise high-voltage DC supply needs.
Operates with 5V DC input voltage, 0 to 5V range. Output voltage of 200V DC with 7.5 mA current and 1.5 W power. Through hole mount configuration for secure PCB installation. Galvanic isolation voltage rated at 500V for safety.
Low ripple and noise at 3% peak-to-peak ensure signal integrity. Wide operating temperature from -25°C to 75°C. Compact and lightweight for space-constrained applications. High reliability with MTBF of 1,862,000 hours. Built-in short circuit protection for enhanced durability.
No external components needed simplifying integration.
This XP Power DC/DC Converter supports industrial, laboratory, and electronic applications requiring isolated, high-voltage DC conversion. It combines compact size, rugged design, and reliable performance, making it an essential component in precision electronic systems. Explore more DC/DC Converters and power solutions with EnvMart’s comprehensive catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model delivers an output voltage of 200V DC at a current of 7.5 mA.
It accepts a 5V DC input voltage range from 0V minimum up to 5V maximum.
The maximum output power is 1.5 W.
The isolation voltage is rated at 500V, providing safety and signal integrity.
The dimensions are 23.37 mm in length, 11.43 mm in width, and 6.35 mm in depth.
It operates reliably within a temperature range of -25°C to 75°C.
This unit has a gross weight of 5.7 grams.
The ripple and noise level is 3% peak-to-peak, ensuring stable voltage output.
No external components are needed, simplifying circuit design.
It is suitable for applications such as avalanche photodiodes, capacitor charging, electrophoresis, and mass spectrometry.
The MTBF is 1,862,000 hours, indicating high reliability.
This model is designed for through hole mounting, facilitating robust PCB assembly.
