Molex KK 396 Series Straight Through Hole Pin Header 13 Contacts 3.96 mm Pitch 1 Row Unshrouded 26-60-4130
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 13 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- The header features a straight orientation with unshrouded male contacts for easy soldering.
- Constructed with a polyester housing and brass contacts plated with tin for durability.
- Designed for through-hole mounting with a 3.96 mm row pitch ensuring compatibility with Molex housings.
- Supports a current rating of 7A and a voltage rating of 250V for robust performance.
- Operates reliably in temperatures ranging from -40°C to 80°C.
- Ideal for use in electronic components, including PCB connectors and wire housings.
- Meets standard quality without specific certifications but ensures dependable connectivity.
Product Description
Molex 26-60-4130 KK 396 Series Straight Through Hole Pin Header is engineered for reliable and precise wire-to-board connections in electronic applications. This unshrouded pin header features 13 male contacts arranged in a single row with a 3.96 mm pitch, facilitating straightforward solder termination and connection to PCB housings.
The connector housing is made from durable polyester material ensuring mechanical stability and insulation, while the brass contacts plated with tin offer excellent conductivity and corrosion resistance. This header supports a current rating of 7A and can handle voltages up to 250V, making it suitable for a wide range of electronic equipment.
Designed for through-hole mounting, the 3.96 mm row pitch is compatible with Molex KK range housings, providing secure and precise mating. Its operating temperature range from -40°C to 80°C guarantees performance in diverse environmental conditions encountered in industrial, manufacturing, and electronics assembly settings.
This pin header is widely used in PCB connectors and wire housing assemblies, supporting industrial and commercial electronics manufacturing needs. It complies with industry standards, although it does not carry specific certifications. The unshrouded design allows flexibility and ease of use in tight PCB layouts.
The header features a straight orientation and is unshrouded. Constructed with polyester housing and brass contacts plated with tin. Supports 7A current and 250V voltage ratings. Has a temperature range between -40°C and 80°C.
Designed for through-hole mounting with a 3.96 mm pitch. Compatible with Molex KK 396 series housings. Suitable for industrial electronics and PCB applications. Explore more from Molex and related electronics components in EnvMart's extensive catalog.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header supports a current rating of 7A.
It has a voltage rating of 250V.
The contacts are arranged with a pitch of 3.96 mm.
This pin header features 13 male contacts.
The housing is made from polyester, and the contacts are brass plated with tin.
It operates reliably in temperatures ranging from -40°C to 80°C.
Yes, it is designed for through-hole mounting.
This model uses solder termination for connections.
No, this pin header features an unshrouded design.
It supports a wire-to-board connector system.
The country of origin for this pin header is India.
This pin header belongs to the KK 396 series.
