Molex KK 396 Series Straight Through Hole Pin Header, 4 Contacts, 3.96 mm Pitch, 1 Row, Unshrouded 26-48-1045

Molex 26-48-1045 KK 396 Series Straight Through Hole Pin Header is a high-quality electronic connector designed to provide secure wire-to-board connections with 4 male contacts arranged in a single row. Featuring a 3.96 mm pitch, this unshrouded pin header is built for through-hole mounting on printed circuit boards, making it versatile for a wide range of electronic assembly applications.

Manufactured with polyester housing, it offers excellent insulation properties and mechanical robustness. The brass contacts, plated with tin, ensure optimal electrical conductivity and resistance to corrosion, enhancing reliability. This model supports a continuous current of up to 7 A and is rated for operational voltages up to 250 V, meeting typical requirements for commercial and industrial electronics.

The pin header supports a temperature range of -40°C to 80°C, allowing it to function in diverse environmental conditions, from low-temperature industrial settings to moderate heat applications. Its tail pin length of 4.37 mm facilitates secure solder termination, ensuring stable mechanical and electrical connections.

This series mates with various Molex connector housings including series 3069, 2139, 6442, and 41695, as well as IDT connectors and other PCB connectors, providing extensive compatibility for design implementations.

4 male contacts arranged in 1-row configuration. 3.96 mm pitch for standard spacing on PCBs. Polyester housing provides insulation and durability. Brass contacts with tin plating ensure conductivity and corrosion resistance.

Supports 7 A current and 250 V voltage ratings. Through-hole mount type with straight orientation. Operational temperature from -40°C to 80°C. Unshrouded design for easy mating. Compatible with a range of Molex connector series.

This Molex KK 396 Series Pin Header is suited for industrial electronics manufacturing, PCB assembly, communication equipment, and other electronic applications requiring reliable wire-to-board connections. It is a key component for engineers and technicians focused on building robust and maintainable electronic systems.
