ASSMANN WSW AWH Series Straight Through Hole PCB Header 10 Contacts 2.54 mm Pitch 2 Row Shrouded AWH 10G-0222-T

ASSMANN WSW AWH 10G-0222-T PCB Header features a straight, through-hole mounting design with 10 contacts arranged in 2 rows at a standard pitch of 2.54 mm. The shrouded connector housing is made of polybutylene terephthalate, providing mechanical protection and durability in demanding industrial applications.

The contacts are crafted from copper alloy and are gold plated to provide low electrical resistance and excellent corrosion resistance, ensuring reliable connectivity over long periods.

This PCB header supports a current rating of 3A and voltages up to 1000V, making it suitable for a wide range of electronic component assemblies and wire-to-board connections. Its operating temperature range from -40°C to 105°C allows use in harsh environments encountered in industrial, manufacturing, and electronic assembly settings.

The connector uses solder termination with male contacts and a straight orientation, facilitating straightforward PCB insertion and soldering processes. Moreover, the product complies with RoHS directive approvals, ensuring it meets environmental and safety regulations applicable in electronics manufacturing.

Features 10 male contacts arranged in 2 rows for compact PCB design. Shrouded housing made from durable polybutylene terephthalate for protection. Gold-plated copper alloy contacts ensure excellent conductivity and corrosion resistance.

Supports continuous current rating of 3A and withstands up to 1000V voltage. Suitable for through-hole mounting with solder termination type. Operates reliably between -40°C and 105°C for various industrial environments.

Compliant with RoHS standards for environmentally safe usage. Connector orientation is straight for ease of PCB assembly.

This PCB header is widely used in industrial electronics, manufacturing equipment assembly, and other applications requiring reliable wire-to-board connection. Its high-quality materials and precision manufacturing standards ensure dependable performance in challenging conditions.
