Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header 5 Contacts 4.2 mm Pitch 1 Row Shrouded 39-30-3058

Molex 39-30-3058 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a shrouded wire-to-board connector featuring 5 contacts with a 4.2 mm pitch and 1 row. It is designed to handle a maximum current of 12A and withstand voltages up to 600V. The connector's nylon housing offers robust insulation and durability in harsh industrial environments.

The header's brass contacts are plated with gold to ensure excellent electrical conductivity and corrosion resistance. It operates across a wide temperature range from -40°C to 105°C, making it suitable for various industrial and commercial applications.

Designed with fully isolated terminals, the connector prevents debris ingress, arcing, and damage during handling. The scoop-proof housing protects the contact pins from damage when mated at severe angles. Additional features include polarization and keying to eliminate misalignment and accidental mismating during assembly.

The positive locking mechanism secures the connection and prevents accidental unmating caused by shock or vibration. An audible click confirms complete mating. Optional versions include PCB retention pegs and mounting flanges to enhance mechanical stability on printed circuit boards.

This Mini-Fit Jr Series header is ideal for high current, high density wire-to-board interconnections in consumer white goods, industrial automation systems, industrial networks, rack-mount servers, switches, routers, and office equipment. It is manufactured in Mexico under stringent quality standards ensuring reliable and safe electrical connections.

This PCB header is shrouded for protection against debris and arcing. Constructed with a nylon housing and brass contacts plated with gold for high conductivity. Designed to carry up to 12A current and operate between -40°C and 105°C.

The connector includes a positive locking mechanism with audible click for secure mating. Features polarization and keying to prevent misalignment and mismating. Ideal for high current and high density wire-to-board applications.

Suitable for consumer appliances, industrial automation, networking equipment, and office electronics. Explore the full range of Molex power connectors and PCB Headers on EnvMart for your electronic and electrical component needs.
