Molex C-Grid III Series Pin Header 22 Contacts 2.54 mm Pitch 1 Row Unshrouded 90120-0782
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 22 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Designed for board to board and wire to board connections.
- Features a breakaway design for customizable length.
- Gold-plated brass contacts ensure high retention and reliable connections.
- Through hole mount type for strong solder joints.
- Operates reliably from -55°C up to 125°C temperature range.
- Compatible with C-Grid III series sockets and crimp housings.
- Supports voltage rating up to 350V and current of 3A.
- Male contact gender with tail pin length of 2.9 mm and mating pin length of 6.75 mm.
Product Description
Molex 90120-0782 C-Grid III Series Straight Through Hole Pin Header is a high-quality connector designed for electronic applications requiring reliable PCB interconnection. It features 22 gold-plated brass contacts arranged in a single row with a 2.54 mm pitch, optimized for wire-to-board mounting with a through-hole solder termination.
The connector supports a current rating of 3A and voltage up to 350V, making it suitable for a range of industrial, telecommunications, medical, consumer, and automotive electronics. Its operating temperature range spans from -55°C to 125°C, ensuring performance under demanding thermal conditions.
This pin header supports the C-Grid III interconnection system, providing a secure mating interface with C-Grid III series sockets and crimp housings. The breakaway design allows customization of pin count for design flexibility, while the unshrouded configuration allows easy inspection and soldering.
The housing is constructed from robust polyester material, providing mechanical stability and ensuring durability during use and soldering processes. The gold-plated brass contacts deliver high retention force offering strong mechanical and electrical connections.
Compatible with board to board and wire to board connections. Breakaway design for adjustable pin count. High retention force and mechanical stability. Operating temperature range from -55°C to 125°C. Rated for 3A current and 350V voltage.
Durable polyester housing and gold-plated brass contacts. Unshrouded type for ease of inspection. Through hole solder termination for stable mounts. Male contact gender with 2.9 mm tail pin length. Suitable for industrial, medical, consumer, telecom, and automotive applications.
This Molex C-Grid III Series pin header is ideal for electronics manufacturing and repair, providing versatile and reliable PCB interconnections required in complex electronic systems. Explore more products in the PCB Pin Header category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this pin header is 350V.
This pin header supports a current rating of 3A.
It operates reliably within a temperature range of -55°C to 125°C.
The pin header features 22 contacts arranged in a single row.
This model uses a through hole mount type for strong solder joints.
The housing is made of polyester, and the contacts are gold-plated brass.
The pitch size of the contacts is 2.54 mm.
The tail pin length is 2.9 mm.
Yes, it is compatible with the C-Grid III series sockets and crimp housings.
The contacts in this model are male gender.
It uses a solder termination type for secure connections.
This model is suitable for industrial, telecommunications, medical, consumer, and automotive electronics applications.
