Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header, 16 Contacts, 4.2 mm Pitch, 2 Rows, Shrouded 39-30-1160
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 13A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Fit Jr |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.6mm |
Key Features
- Current rating up to 13A per circuit ensures high power handling.
- Constructed with durable nylon housing for enhanced insulation.
- Right angle orientation with through-hole mount for PCB integration.
- Fully isolated, scoop-proof terminals prevent contact damage.
- Positive locking mechanism secures mating connection with audible click confirmation.
- Contact material is brass plated with tin for corrosion resistance.
- Operates reliably from -40°C to 105°C maximum temperature range.
- Wire-to-board connector system designed to prevent misalignment and mismating.
Product Description
Molex 39-30-1160 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a wired power connector with 16 male contacts arranged in two rows with 4.2 mm pitch. Designed for robust electrical performance, it supports currents up to 13A per circuit at 600V.
The connector's nylon housing offers excellent insulation and is shrouded and scoop-proof to prevent damage to the terminals during mating. It features polarization and keying to avoid misalignment and ensures a positive locking mating with an audible click, enhancing connection security against shocks and vibrations.
Operating in harsh environments, this PCB header maintains performance across a wide temperature range from -40°C to 105°C. Its brass contacts plated with tin provide durable, corrosion-resistant connections, terminated by solder with a tail pin length of 3.6 mm.
This series is ideally suited for applications requiring reliable high current wire-to-board connections such as consumer white goods, office electronics, industrial automation systems, rack-mount servers, routers, and switches.
High current capacity up to 13A per circuit. Durable nylon housing with scoop-proof design. Right angle and through-hole mount style for PCB integration. Positive locking connector with audible mating confirmation. Fully isolated and polarized contacts prevent mishandling and misalignment.
Wide temperature range from -40°C to 105°C ensures operational reliability. Corrosion-resistant brass contacts with tin plating. Suitable for industrial, commercial, and consumer electronics applications. Choose Molex Mini-Fit Jr Series connectors for dependable, high-density power PCB connections. Discover more components in the Electronics Components section of EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of up to 13A per circuit.
The maximum operating temperature is 105°C.
This model uses a through-hole mount type for PCB integration.
It has 16 male contacts arranged in two rows.
The pitch of the contacts is 4.2 mm.
The housing is made of durable nylon, and the contacts are brass plated with tin for corrosion resistance.
It has a voltage rating of 600V.
Yes, it features a positive locking mechanism that secures the mating connection with an audible click confirmation.
The tail pin length is 3.6 mm.
It operates reliably within a temperature range from -40°C to 105°C.
Yes, it features polarization and keying to avoid misalignment and ensure secure connections.
The country of origin for this model is Mexico.
