Texas Instruments Operational Amplifier TLC2272AID, 2.2 MHz Gain Bandwidth, 8-Pin SOIC Package, 5-8V Supply
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | TLC2272AID |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TLC2272 |
| Output Current | 50mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | REACH, RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 8V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 2.2MHz |
| Input Bias Current | 800 pA |
| Vos - Input Offset Voltage | 1.5 mV |
| Slew Rate | 3.6V/μs |
Key Features
- Provides two amplifier channels in one device.
- Supports supply voltage range from 5V to 8V for flexible applications.
- Features low input bias current of 800 pA for precision signal processing.
- Offers a slew rate of 3.6 V/μs ensuring fast response time.
- Compact dimensions with a length of 4.9 mm and width of 3.91 mm.
- Meets industrial standards including REACH and RoHS compliance.
- Wide operating temperature range from -40°C to 125°C for harsh environments.
- Capable of output current up to 50 mA to drive loads effectively.
Product Description
Texas Instruments TLC2272AID is a LinCMOS operational amplifier featuring a gain bandwidth product of 2.2 MHz suitable for a variety of industrial and electronic applications. Packaged in an 8-pin SOIC surface-mount form, it supports supply voltages ranging from 5 to 8 volts, enabling versatility in design environments.
This dual-channel amplifier chip exhibits low input bias current (800 pA) and a fast slew rate of 3.6 V/μs, which makes it ideal for precision analog signal conditioning and high-speed amplification tasks. Its compact size with a length of 4.9 mm, width of 3.91 mm, and height of 1.58 mm allows for efficient PCB layout and space saving.
The device operates reliably across a wide temperature range from -40°C to 125°C, suitable for industrial, automotive, and HVAC control systems. Conformance with REACH and RoHS directives assures environmental compliance. Additionally, the TLC2272AID meets the AEC-Q100 automotive standard, indicating its robustness for automotive electronics applications.
Dual channel LinCMOS operational amplifier with 2.2 MHz gain bandwidth product. 8-pin SOIC surface mount package for compact PCB integration. Wide supply voltage range of 5 V to 8 V for design flexibility. Low input bias current enhances precision in measurement circuits.
Fast slew rate suitable for responsive signal amplification. Operating temperature range supports demanding industrial environments. Compliance with REACH and RoHS environmental standards. Output current of up to 50 mA for driving moderate loads.
Automotive-grade qualification (AEC-Q100) ensures high reliability.
Typical applications include amplifiers and comparators in electronics manufacturing, automotive control circuits, industrial automation, and instrumentation. This product enables designers to maintain optimal performance with reliable and efficient analog signal manipulation.
Explore more Operational Amplifiers and semiconductor solutions on EnvMart to enhance your electronic designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TLC2272AID has a gain bandwidth product of 2.2 MHz, making it suitable for various industrial and electronic applications.
This model supports a supply voltage range from 5V to 8V, providing flexibility for different design requirements.
It is capable of delivering an output current of up to 50 mA, allowing it to effectively drive moderate loads.
The dimensions of this operational amplifier are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
The input bias current for the TLC2272AID is 800 pA, which enhances precision in measurement circuits.
This model operates reliably within a temperature range of -40°C to 125°C, making it suitable for harsh environments.
The operational amplifier is packaged in an 8-pin SOIC surface-mount form, allowing for compact PCB integration.
The slew rate of this operational amplifier is 3.6 V/μs, which ensures a fast response time for signal amplification.
Yes, it meets REACH and RoHS compliance standards, ensuring it adheres to environmental regulations.
This operational amplifier meets the AEC-Q100 automotive standard, indicating its suitability for automotive applications.
The TLC2272AID features two amplifier channels in one device, allowing for versatile applications.
The input offset voltage for this operational amplifier is 1.5 mV, which is important for precision applications.
