Panasonic ECHU1C103GX5 16 V dc 16V ac 10 nF Surface Mount Film Capacitor ECHU(X) Series
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 1.1mm |
| Length | 2mm |
| Model | ECHU1C103GX5 |
| Width | 1.25mm |
| Mount Type | Surface |
| Series | ECHU(X) |
| Maximum Operating Temperature | 125°C |
| Capacitance | 10nF |
| Standards/Approvals | RoHS |
| Rated AC Voltage | 16V ac |
| Rated DC Voltage | 16V dc |
Key Features
- Constructed from stacked metallised PPS film with mould-less construction.
- Capable of withstanding 125°C maximum operating temperature.
- Designed specifically for reflow soldering processes.
- Suitable for time-constant, oscillation, resonance, filtering, and audio circuit applications.
- Features low equivalent series resistance (ESR) for improved performance.
- Compact dimensions of 2mm length, 1.25mm width, and 1.1mm height.
- RoHS compliant, ensuring environmental safety standards.
- Lightweight surface mount design for efficient PCB integration.
Product Description
Panasonic ECHU1C103GX5 is a high-quality surface mount film capacitor from the ECHU(X) series, rated for 16V ac and 16 V dc operation with a capacitance of 10 nF.
Constructed from stacked metallised PPS film using a mould-less design, this capacitor provides excellent reliability and performance under demanding conditions, with a maximum operating temperature of 125°C.
The compact size of 2mm length, 1.25mm width, and 1.1mm height makes it ideal for space-constrained applications on printed circuit boards.
This film capacitor is optimized for use in time constant circuits, oscillation and resonance circuits, filtering stages, and audio signal processing due to its low ESR characteristics.
The component supports reflow soldering processes, contributing to manufacturing efficiency and assembly automation. These capacitors meet RoHS standards, ensuring compliance with environmental regulations. Constructed from stacked metallised PPS film with mould-less construction.
Capable of withstanding 125°C maximum operating temperature. Designed specifically for reflow soldering processes. Suitable for time-constant, oscillation, resonance, filtering, and audio circuit applications. Features low equivalent series resistance (ESR) for improved performance.
Compact dimensions of 2mm length, 1.25mm width, and 1.1mm height. RoHS compliant, ensuring environmental safety standards. Lightweight surface mount design for efficient PCB integration.
This Panasonic film capacitor is commonly used in electronic manufacturing, industrial electronics, automotive electronics (non-automotive standard), audio equipment, and filtering applications within industrial, laboratory, and commercial electronics environments.
Explore more Panasonic electronic components or browse the Film Capacitor category on EnvMart for complementary products to support your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 10 nF.
It is rated for 16V ac and 16V dc operation.
The maximum operating temperature is 125°C.
The dimensions are 2mm in length, 1.25mm in width, and 1.1mm in height.
This model supports surface mounting.
It is constructed from stacked metallised PPS film using a mould-less design.
Yes, it is RoHS compliant, ensuring adherence to environmental safety standards.
It is suitable for time-constant, oscillation, resonance, filtering, and audio circuit applications.
This capacitor features low equivalent series resistance (ESR) for improved performance.
Yes, it is designed specifically for reflow soldering processes, enhancing manufacturing efficiency.
The country of origin for this capacitor is India.
It belongs to the ECHU(X) series of capacitors.
