Panasonic PPS Film Surface Mount Film Capacitor 16V DC 16V AC 47nF ECHU1C473GX5

Panasonic ECHU1C473GX5 PPS Film Capacitor is a surface mount electronic component designed for high performance in various electronic applications. Rated at 16V DC and 16V AC with 47nF capacitance, this film capacitor utilizes stacked metallised PPS film layers providing excellent electrical stability and durability.

The capacitor supports a maximum operating temperature of 125°C ensuring reliable operation in demanding industrial and commercial electronics environments. Its compact dimensions of 3.2 mm length, 1.6 mm width, and 1.5 mm height make it ideal for space-constrained PCB designs.

Constructed with a mould-less approach, it offers a lightweight and compact design and is optimized for reflow soldering processes which facilitates efficient assembly in automated manufacturing lines.

This ECHU(X) series film capacitor is especially suited for electrical circuits involving time-constant applications, oscillation and resonance handling, signal filtering, and audio circuits due to its low Equivalent Series Resistance (ESR).

Constructed from stacked metallised PPS film for durability and stability. Compact and lightweight design enables high-density PCB layouts. Supports reflow soldering manufacturing processes effectively. High maximum operating temperature rating at 125°C for robustness.

Low ESR makes it suitable for precision filtering applications. Surface mount type for easy automated assembly. Conforms to RoHS directive ensuring environmental safety. Not designed for automotive standards compliance.

This Film Capacitor is commonly used in industrial electronics, communication devices, audio systems, and other applications requiring reliable capacitive components with stable performance over temperature and frequency variations. Explore the Panasonic family of electronic components for your high quality and efficient industrial solutions.
