Molex Sabre Series Straight Through Hole PCB Header 6 Contacts 7.5 mm Pitch 1 Row Shrouded 43160-2106
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Straight |
| Current | 18A |
| Mount Type | Through Hole |
| Contact Material | Brass |
| Series | Sabre |
| Termination Type | Solder |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 7.5mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.81mm |
Key Features
- Designed for wire-to-board connector applications with a straight orientation.
- Rated for current up to 18A and voltage up to 600V.
- Manufactured with brass contact material and tin plating for reliable conductivity.
- Features male contacts with 3.81 mm tail pin length for easy solder termination.
- Operates in temperature range from -40°C to 75°C for robust industrial use.
- Includes positive locking casings to prevent accidental disconnection.
- Shrouded design ensures complete insulation and correct mating via polarized casing.
- Suitable for high current applications with UL and CSA compliance.
Product Description
Molex 43160-2106 Sabre Series represents a premium straight through hole PCB header engineered for high-reliability wire-to-board connections. This product features 6 male contacts arranged in a single row with a 7.5 mm pitch, optimally designed for applications requiring up to 18 amp current and voltage ratings of 600 volts. The shrouded connector system provides enhanced safety and polarization to ensure correct and secure mating, while the tin-plated brass contacts offer excellent conductivity and corrosion resistance.
Designed to operate reliably in a temperature range from -40°C to 75°C, this connector supports a broad array of industrial, manufacturing, and electronic assembly applications. The contacts include harpoon fixings to secure insertion on PCBs and terminate by soldering with 3.81 mm tail lengths. Its positive locking casing ensures audible clicks on engagement, mitigating the risk of accidental disconnection in critical systems.
Molex Sabre Series connectors are developed to meet stringent UL and CSA standards, underscoring their suitability for power connectors in commercial and industrial environments. Its wire-to-board system facilitates easy integration in control panels, electrical equipment, instrumentation, and power distribution units.
Designed for wire-to-board connection with high current capacity up to 18A. Shrouded single-row male header with 7.5 mm pitch for secure mating. Brass contacts plated with tin improve durability and conductivity. Operating temperature range from -40°C to +75°C ensures robust performance.
Positive locking with audible click prevents accidental disconnection. Harpoon fixing contacts for secure PCB placement. Complies with UL E29179, UL1950, and CSA LR19980 standards. Termination type solder compatible with wave or hand soldering processes.
Ideal for industrial electronics, power supply units, and control equipment.
This Molex Sabre Series PCB header is an excellent choice for engineers requiring reliable, high-performance connectors for power and signal applications in industrial and commercial electronics. Explore more PCB connectors and related products in our Electronics Components category at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 18A.
It has a voltage rating of up to 600V.
The contacts are arranged with a pitch of 7.5 mm.
This unit uses solder termination, compatible with both wave and hand soldering processes.
It operates reliably within a temperature range of -40°C to 75°C.
This model features 6 male contacts arranged in a single row.
The contacts are made of brass and are plated with tin for improved conductivity.
Yes, it includes a positive locking casing that ensures secure engagement with an audible click to prevent accidental disconnection.
Yes, it is designed for high current applications with a capacity of up to 18A.
The tail pin length of the contacts is 3.81 mm, facilitating easy solder termination.
This model complies with UL E29179, UL1950, and CSA LR19980 standards.
It uses a through hole mounting type, suitable for PCB applications.
