Molex C-Grid III Series Right Angle Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90121-0772
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Suitable for board to board and wire to board applications.
- Right angle orientation with through hole mount type.
- Contact material is brass with gold plating for reliable conductivity.
- Breakaway design allows cutting to size for flexible PCB layout.
- Operates within -55°C to 125°C temperature range.
- Supports voltage up to 350V and current rating of 3A.
- High mechanical stability once soldered to PCB.
- Tail pin length of 2.9mm and mating pin length of 6.75mm ensure secure mating.
Product Description
Molex 90121-0772 C-Grid III Series Right Angle Through Hole Pin Header is designed for robust and flexible interconnection in electronic assemblies. This pin header features 12 contacts arranged in a single row with a precise 2.54 mm pitch, ensuring optimal spacing for soldering and secure electrical contact.
The right angle configuration facilitates wire-to-board connections on printed circuit boards, providing an ideal solution for space-constrained designs. The through hole mounting type enhances mechanical strength by securing pins firmly onto the PCB.
Constructed with brass contacts plated in high-quality gold, this header ensures consistent conductivity and corrosion resistance. The polyester housing material supports durability under various environmental conditions.
This pin header has a breakaway design allowing users to customize the length and number of contacts to suit specific application requirements. The tail pin length is 2.9 mm, and the mating pin length is 6.75 mm, maintaining secure and reliable connections.
Operating temperatures range from -55°C to 125°C. The device supports up to 350V and 3 amperes of current, making it suitable for industrial, computer, medical, telecommunications, and automotive safety equipment applications.
Suitable for board to board and wire to board applications. Right angle orientation with through hole mount type. Gold-plated brass contacts for enhanced conductivity and durability. Breakaway feature for design flexibility.
High mechanical stability once soldered to PCB. Wide operating temperature range from -55°C to 125°C. Voltage rating of 350V and current rating of 3A. Polyester housing material for robust durability. Unshrouded male contact suitable for diverse applications.
Ideal for industrial, computer, medical, telecommunications, and automotive use.
This Molex C-Grid III Series pin header fulfills the demanding requirements of modern interconnection systems with reliability and precision. Browse EnvMart's extensive range of PCB Headers and connectors to find compatible accessories and complementary products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header supports a voltage rating of 350V and a current rating of 3A.
It features a pitch of 2.54 mm and has 12 contacts arranged in a single row.
The operating temperature range is from -55°C to 125°C.
The contacts are made of brass with gold plating, and the housing is constructed from polyester.
This model uses a through hole mounting type, which enhances mechanical strength once soldered to the PCB.
The tail pin length is 2.9 mm, while the mating pin length is 6.75 mm.
It has a right angle orientation, which facilitates wire-to-board connections.
Yes, it is suitable for both board-to-board and wire-to-board applications.
This model utilizes a solder termination type.
It features a breakaway design that allows users to cut it to size for flexible PCB layouts.
The contact gender is male, suitable for various applications.
The country of origin for this pin header is India.
