Texas Instruments Operational Amplifier 5.5 MHz Dual Channel 8-Pin SOIC Surface Mount OPA2376AID

Texas Instruments OPA2376AID is a high precision operational amplifier designed for demanding analog signal applications requiring low offset voltage and low drift across temperature. This dual channel amplifier features a gain bandwidth product of 5.5 MHz and operates from a supply voltage of 3 V to 5.5 V, ensuring flexibility for low voltage battery-powered and automotive systems. Its low input bias current of 10 pA and input offset voltage of 25 µV make it ideal for accurate measurement and signal conditioning.

Packaged as an 8-pin small outline integrated circuit (SOIC), it is suitable for surface mount technology (SMT) assembly providing compact PCB layout. The amplifier complies with the automotive standard AEC-Q100, proving its robustness for automotive and industrial applications.

Typical uses include transducer and strain gauge amplifiers, precision integrators, active filters, instrumentation systems, and other areas demanding high accuracy and stability. Its slew rate of 2 V/µs ensures reliable transient response for dynamic signals.

The device measures 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height, facilitating integration in space-constrained electronic systems. Dual channel operational amplifier with 8-pin SOIC package. Gain bandwidth product of 5.5 MHz for precision signal conditioning.

Supply voltage range from 3 V to 5.5 V for versatile applications. Low input offset voltage and bias current for minimal signal error. Wide operating temperature range from -40°C to 125°C for reliable operation. Automotive grade AEC-Q100 certification for industrial robustness.

Compact dimensions suitable for PCB designs with limited space. Slew rate of 2 V/µs for efficient transient response. Surface mount SOIC package ensures compatibility with automated assembly.

This operational amplifier is commonly used in industrial, automotive, medical instrumentation, laboratory equipment, and communication electronics where precise analog amplification is critical.
