Texas Instruments Operational Amplifier 5.8 MHz 8-Pin 22V SOIC TLE2141ACD
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | TLE2141ACD |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TLE2141 |
| Output Current | 80mA |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 22V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 5.8MHz |
| Input Bias Current | -1.6 μA |
| Slew Rate | 45V/μs |
| Input Offset Current | 150 nA |
Key Features
- Designed for surface mounting in SOIC package with 8 pins.
- Single channel operational amplifier operating between 5 V and 22 V supply voltages.
- Gain bandwidth product of 5.8 MHz enables precision signal amplification.
- Slew rate of 45 V/μs supports rapid voltage changes.
- Low input bias current of -1.6 μA for improved accuracy.
- Operating temperature range from 0°C to 70°C ensures stable performance.
- Complies with RoHS standards and automotive AEC-Q100 qualification.
- Maximum output current of 80 mA suitable for a variety of applications.
Product Description
The Texas Instruments TLE2141ACD is a high-performance operational amplifier designed for precision signal amplification across industrial, automotive, and electronic applications. Operating with a gain bandwidth product of 5.8 MHz, it supports fast and accurate analog signal processing.
Encased in a compact 8-pin SOIC surface-mount package, this device facilitates efficient PCB assembly and reliable operation. Its operating voltage range of 5 V to 22 V provides versatility for various power supply configurations, while the 45 V/μs slew rate enables quick response to input changes. The low input bias current and offset voltage ensure minimal signal error in sensitive measurement or control circuits.
This amplifier meets RoHS compliance and is also qualified to the automotive AEC-Q100 standard, making it suitable for use in demanding environments that require stringent quality and reliability standards.
With maximum output current capability of 80 mA and stable operation from 0°C to 70°C, the TLE2141ACD is suited for use in electronic instrumentation, control systems, and automotive electronics requiring precision amplification.
Surface mount 8-pin SOIC package supports compact circuit designs. Single channel operation with wide supply voltage range from 5 V to 22 V. Gain bandwidth product of 5.8 MHz for precision amplification. High slew rate of 45 V/μs for fast transient response.
Low input bias current and offset voltage enhances signal integrity. Automotive standard AEC-Q100 qualification ensures reliability. RoHS compliant for environmental and safety standards adherence. Compact physical dimensions facilitate dense electronic designs.
Operates reliably across 0°C to 70°C ambient temperature range. Maximum 80 mA output current for flexible load driving.
This operational amplifier from Texas Instruments is ideal for diverse applications including industrial instrumentation, automotive electronics, laboratory equipment, and consumer devices. Its precision, compliance with quality standards, and compact footprint ensure it meets the requirements of modern electronics design.
Explore the complete range of Operational Amplifiers from Texas Instruments in our Electronics & Electricals category at EnvMart for industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the TLE2141ACD is 5.8 MHz, enabling precision signal amplification.
This operational amplifier can provide a maximum output current of 80 mA, suitable for various applications.
It operates within a supply voltage range of 5 V to 22 V, providing versatility for different power supply configurations.
The slew rate of this model is 45 V/μs, which supports rapid voltage changes.
The dimensions of this operational amplifier are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
The input bias current is -1.6 μA, which enhances accuracy in sensitive applications.
This model operates reliably across an ambient temperature range from 0°C to 70°C.
It is encased in a compact 8-pin SOIC surface-mount package, facilitating efficient PCB assembly.
Yes, it complies with RoHS standards and is qualified to the automotive AEC-Q100 standard, ensuring reliability in demanding environments.
The input offset current is 150 nA, contributing to minimal signal error in applications.
The TLE2141ACD is a single channel operational amplifier.
It is suitable for applications in industrial instrumentation, automotive electronics, laboratory equipment, and consumer devices requiring precision amplification.
