Molex Pico-Clasp Series Right Angle Surface PCB Header 8 Contacts 1 mm Pitch Single Row Shrouded 501568-0807

Molex 501568-0807 Pico-Clasp Series Right Angle Surface PCB Header is a high-density single row wire-to-board connector system designed for compact electronic applications. Featuring 8 contacts with a 1 mm pitch, this shrouded header ensures reliable connection with positive locking for stability in demanding environments.

The right angle orientation allows efficient use of PCB space, making it ideal for compact assemblies in consumer electronics, industrial controls, and telecommunications equipment. Constructed with a nylon housing for durability and brass contacts with tin plating, it balances mechanical strength and superior conductivity.

This connector supports a current of 1A and voltage up to 50V, suitable for low power electronic circuits. Operable in a wide temperature range from -40°C to 105°C, it provides consistent performance across various industrial and commercial conditions. The solder termination method facilitates secure PCB mounting ensuring long term reliability.

Its shrouded design protects contacts from damage and prevents incorrect mating, enhancing robustness in applications such as industrial automation, instrumentation, and embedded systems. The 1 mm pitch and mating pin length of 1 mm provide precision alignment and connection integrity.

The Molex Pico-Clasp series is known for compact design and positive locking features, supporting wire-to-board interconnections with 2 to 15 circuits for single row options. This particular model, 501568-0807, is made in Japan, reflecting high manufacturing standards and quality assurance.

This PCB header features a right angle orientation for space-saving mounting. The connector housing is made of robust nylon material for durability. Contacts are brass with tin plating, ensuring reliable electrical conductivity.

It supports a current rating of 1 ampere and voltage of 50 volts. Suitable for surface mount applications with a wire-to-board connector system. The termination type is solder, providing secure connections. Operating temperature ranges from -40°C to 105°C, suitable for various environments.

Mating pin length is 1 mm, matching the 1 mm row pitch. Shrouded design offers protection to the contacts and enhances connector reliability.

Ideal for use in electronics manufacturing, laboratory equipment, telecommunications, industrial machinery, and consumer electronics, the Molex 501568-0807 gives engineers a reliable, compact, and high-quality PCB connection solution. Browse related PCB header products for additional configurations and designs available at EnvMart.
