Molex Pico-Clasp Series Right Angle Surface PCB Header 3 Contact 1 mm Pitch 1 Row Shrouded 501568-0307
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Pico-Clasp |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 1mm |
Key Features
- Features a shrouded, right angle connector with a single row configuration.
- Constructed with nylon housing and brass contacts plated with tin for durability.
- Designed to operate at voltages up to 50V and current of 1A.
- Operates within a temperature range from -40°C to 105°C for versatility.
- Supports surface mount technology with solder termination for PCB installation.
- Includes contacts with a pin length of 1mm ensuring secure mating.
- Compact 1mm row pitch makes it ideal for high-density circuit applications.
- Manufactured in Japan ensuring quality and reliability in electrical connectors.
Product Description
Molex 501568-0307 Pico-Clasp Series Right Angle Surface PCB Header is a highly compact, wire-to-board connector specifically designed for dense PCB assemblies requiring reliable signal and power transmission. Featuring a 1 mm pitch and three brass contacts arranged in a single shrouded row, this header supports secure mechanical locking at the connection interface, ensuring stability in industrial and consumer electronics.
The nylon housing provides excellent insulation and durability suitable for operating temperatures from -40°C up to 105°C, accommodating a wide range of environmental conditions. The contact surfaces are tin-plated brass, offering corrosion resistance and reliable solder termination with a pin length of 1 mm optimized for surface PCB mounting.
This connector supports wire-to-board applications requiring a current rating of 1A and voltage up to 50V, fitting perfectly into compact electronics such as communication equipment, instrumentation, and automotive control modules. The right angle orientation enables flexible PCB design while the shrouded design ensures protection from accidental disconnections.
The Molex Pico-Clasp™ system is recognized as one of the smallest positive locking connector systems on the market, making it suitable for high-density interconnection needs in modern electronic devices.
Shrouded right angle wire-to-board connector for robust connection. Durable nylon housing supports harsh operating conditions. Tin-plated brass contacts ensure reliable conductivity and solderability. Compact 1 mm pitch and single row design for space-saving PCB layouts.
Temperature rated from -40°C to 105°C for versatile applications. Manufactured in Japan with high quality standards. Ideal for industrial, telecommunications, automotive, and consumer electronics. Explore the complete range of Molex PCB connectors and components in EnvMart for your electronic assembly needs and ensure trusted performance with high-quality connectors.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB header is 50V.
This model has a current rating of 1A.
It operates within a temperature range from -40°C to 105°C.
The header features three contacts arranged in a single row.
This connector uses solder termination for PCB installation.
The housing is made of nylon, and the contacts are brass plated with tin.
The pitch size is 1mm, making it suitable for high-density circuit applications.
This model features a shrouded design, providing protection against accidental disconnections.
The orientation of this header is right angle, allowing for flexible PCB design.
This PCB header is manufactured in Japan, ensuring quality and reliability.
It is suitable for wire-to-board applications in industrial, telecommunications, automotive, and consumer electronics.
The contacts in this connector are male.
