Nexperia 1.91 V Zener Diode, Single Element, 365 mW Power Dissipation, 5% Tolerance, Surface Mount BZX8850S-C9V1YL

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1.91 V Zener Diode, Single Element, 365 mW Power Dissipation, 5% Tolerance, Surface Mount BZX8850S-C9V1YL

Name: Nexperia 1.91 V Zener Diode, Single Element, 365 mW Power Dissipation, 5% Tolerance, Surface Mount BZX8850S-C9V1YL
Brand: Nexperia
SKU: 115477
Price: 0.06 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	0.47mm
Length	1mm
Model	BZX8850S-C9V1YL
Mount Type	Surface
Series	BZX8850S
Maximum Operating Temperature	150°C
Working voltage range	nominal 1.8 V to 75 V
Package Type	DFN1006BD-2
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	365mW
Diode Configuration	Single
Test Current It	50μA
Maximum Reverse Leakage Current	100nA
Nominal Zener Voltage Vz	9.1V
Zener Type	Voltage Regulator
Maximum Zener Impedance	100Ω
Typical Voltage Temperature Coefficient	3.8mV/K

Key Features

Nominal Zener voltage is 9.1 V with a tolerance of ±5%.
Low test current of 50 μA ensures efficiency in low bias circuits.
Package type is leadless surface mount with side-wettable flanks ensuring reliable PCB mounting.
Maximum reverse leakage current is low at 100 nA for minimal current loss.
Operating temperature ranges from -55°C to 150°C suitable for automotive and industrial use.
Typical voltage temperature coefficient is 3.8 mV/K for voltage stability over temperature.
Complies with automotive standard AEC-Q101 for quality assurance.
Maximum Zener impedance is 100 Ω to ensure proper regulation.

Product Description

Nexperia BZX8850S-C9V1YL is a new single element voltage regulator Zener diode with a nominal voltage of 9.1 V, maximum power dissipation of 365 mW, and 5% voltage tolerance. Packaged in a leadless surface mount DFN1006BD-2 (SOD882BD) device, it provides reliable voltage regulation with excellent thermal performance suitable for compact and space-constrained electronic designs.

This diode operates efficiently at a low test current of 50 μA, making it highly suitable for low bias and portable battery-powered applications. The device features low maximum reverse leakage current of 100 nA and a maximum Zener impedance of 100 Ω ensuring stable voltage regulation.

The diode's operating temperature range of -55°C to 150°C and compliance with automotive standard AEC-Q101 make it dependable for automotive, industrial, and commercial electronics. Its small form factor with dimensions of 1 mm length and 0.47 mm height enables installation in miniature assemblies on PCB surfaces.

The typical voltage temperature coefficient is 3.8 mV/K, offering consistent voltage characteristics over varying temperatures. The diode accepts a working voltage range from nominal 1.8 V up to 75 V, accommodating multiple electronic design requirements.

Single element diode configuration designed for voltage regulation. Leadless surface mount package with side-wettable flanks for secure soldering. Compact and low-profile design suited for space-constrained boards. Low power dissipation rating ensures efficient operation.

Wide operating temperature range supports harsh environments. Compliance with AEC-Q101 automotive quality standards. Low test current minimizes power consumption in circuits. Stable operation due to tight voltage tolerance and impedance.

Ideal for general voltage regulation in electronic, automotive, industrial applications.

This Nexperia Zener diode model BZX8850S-C9V1YL is an ideal component choice for designers seeking reliable voltage regulation in embedded systems, portable devices, and automotive electronics. Explore more semiconductor components and voltage regulators on EnvMart for comprehensive industrial solutions.
