Nexperia 12 V 365 mW Surface Mount Zener Diode Single 5 % Tolerance 2-Pin DFN1006BD-2 BZX8850S-C12YL
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C12YL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 12V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 150Ω |
| Typical Voltage Temperature Coefficient | 6mV/K |
Key Features
- The package type is DFN1006BD-2 with 2 pins designed for surface mounting.
- Nominal Zener voltage is 12 V with a test current of 50 μA, ideal for low bias applications.
- The diode features a maximum power dissipation of 365 mW and a maximum Zener impedance of 150 Ω.
- Supports an operating temperature range from -55°C to 150°C with AEC-Q101 automotive standard compliance.
- The device is suitable for battery-powered portable applications requiring low-current voltage regulation.
- The zener voltage tolerance is ±5 % with a typical voltage temperature coefficient of 6 mV/K.
- The diode package is ultra-small with a height of 0.47 mm and length of 1 mm, enabling compact PCB design.
Product Description
Nexperia BZX8850S-C12YL is a 12 V single element Zener Diode in a compact DFN1006BD-2 surface-mount package designed for voltage regulation in electronic circuits. This discrete semiconductor offers a maximum power dissipation of 365 mW and ±5 % voltage tolerance, making it ideal for precise voltage regulation in low power applications.
The device operates efficiently within a temperature range of -55°C to 150°C and complies with the automotive standard AEC-Q101, ensuring reliability in automotive and industrial environments. Its low test current of 50 μA suits portable and battery-powered devices where power conservation is critical.
The compact 2-pin DFN1006BD-2 package with a height of 0.47 mm and length of 1 mm allows for high-density PCB layouts. The maximum Zener impedance of 150 Ω and maximum reverse leakage current of 50 nA ensure stable performance under varying operating conditions.
This voltage regulator diode is widely applicable in industrial electronics, automotive systems, consumer electronics, and power supply protection circuits. It efficiently maintains voltage within the specified limits to protect sensitive components from voltage spikes.
The BZX8850S series is known for its low current general regulation functions and broad working voltage range from nominal 1.8 V to 75 V, enabling versatile use in various circuit designs.
The package type is DFN1006BD-2 with 2 pins designed for surface mounting. Nominal Zener voltage is 12 V with a test current of 50 μA, ideal for low bias applications. The diode features a maximum power dissipation of 365 mW and a maximum Zener impedance of 150 Ω.
Supports an operating temperature range from -55°C to 150°C with AEC-Q101 automotive standard compliance. The device is suitable for battery-powered portable applications requiring low-current voltage regulation. The zener voltage tolerance is ±5 % with a typical voltage temperature coefficient of 6 mV/K.
The diode package is ultra-small with a height of 0.47 mm and length of 1 mm, enabling compact PCB design. Explore more high-quality semiconductor components like this in the Electronics & Electricals category at EnvMart, your industrial product sourcing platform.
Explore more products in our Zener Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal Zener voltage of this diode is 12 V.
The maximum power dissipation for this model is 365 mW.
This Zener diode comes in a DFN1006BD-2 package type and has 2 pins.
The operating temperature range for this diode is from -55°C to 150°C.
The maximum Zener impedance of this model is 150 Ω.
The test current for this model is 50 μA.
This diode complies with the AEC-Q101 automotive standard.
The typical voltage temperature coefficient of this Zener diode is 6 mV/K.
The maximum reverse leakage current for this device is 50 nA.
This Zener diode is suitable for battery-powered portable applications requiring low-current voltage regulation.
The dimensions of this model are a height of 0.47 mm and a length of 1 mm.
The working voltage range for this Zener diode is nominally from 1.8 V to 75 V.
