Abracon 24 MHz Crystal Unit ±30 ppm HC-49-US 2-Pin Through Hole Mount ABLS-24.000MHZ-K4F-T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 4.2mm |
| Length | 11.5mm |
| Model | ABLS-24.000MHZ-K4F-T |
| Packaging | Tape & Reel |
| Width | 4.7mm |
| Mount Type | Through Hole |
| Series | ABLS |
| Maximum Operating Temperature | 70°C |
| Package Type | HC-49-US |
| Minimum Operating Temperature | 0°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Standard Frequency | 24MHz |
| Load Capacitance | 16pF |
| Series Resistance | 100Ω |
Key Features
- The crystal unit operates at a standard frequency of 24 MHz.
- It is designed for through hole mounting with a 2-pin configuration.
- The package type is HC-49-US, measuring 11.5 mm length, 4.7 mm width, and 4.2 mm height.
- The load capacitance is rated at 16 pF to ensure circuit compatibility.
- It has a frequency stability of ±50 ppm and series resistance of 100 Ω.
- Operating temperature ranges from 0°C to 70°C for reliable performance.
- The crystal unit is RoHS compliant and comes in tape & reel packaging for automated assembly processes.
- Suitable for numerous electronic applications including computers, modems, microprocessors, and wireless devices.
Product Description
Abracon ABLS-24.000MHZ-K4F-T is a high-quality 24 MHz Crystal Unit designed for precision frequency applications. Featuring a ±30 ppm frequency tolerance and ±50 ppm frequency stability, this crystal unit ensures accurate signal timing in a wide range of electronic circuits.
Its through hole mount and 2-pin configuration, housed in a compact HC-49-US package, makes it ideal for integrating into printed circuit boards requiring a stable oscillator source. The unit measures 11.5 mm in length, 4.7 mm in width, and 4.2 mm in height, suitable for diverse electronic designs.
With a load capacitance of 16 pF and series resistance of 100 Ω, the ABLS-24.000MHZ-K4F-T is optimized for reliable operation between temperatures of 0°C and 70°C. This makes it well suited to applications in computers, modems, microprocessors, and wireless communication equipment, where precise timing and frequency control are critical.
The crystal unit is RoHS compliant, lead-free, and supplied in tape and reel packaging to facilitate automated manufacturing processes. The robust HC-49-US package offers durability and longevity in industrial, commercial, and laboratory settings.
Standard frequency of 24 MHz for accurate timing. Through hole mount with 2-pin configuration for ease of use. Compact HC-49-US package dimensions: 11.5 mm x 4.7 mm x 4.2 mm. 16 pF load capacitance and 100 Ω series resistance for electrical compatibility.
Operating temperature range of 0°C to 70°C for consistent performance. RoHS compliant and lead free for environmental safety. Tape and reel packaging suitable for automated assembly. Ideal for electronics including computers, modems, microprocessors, and wireless devices.
This Abracon crystal unit supports precision timing and stable frequency generation necessary for industrial, commercial, laboratory, and manufacturing electronics applications. Explore our curated selection of electronic components and Crystal Units at EnvMart for reliable and certified products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this crystal unit is 24 MHz, ensuring accurate timing for electronic applications.
The load capacitance for this model is rated at 16 pF, which ensures compatibility with various circuits.
The dimensions of the HC-49-US package are 11.5 mm in length, 4.7 mm in width, and 4.2 mm in height.
The operating temperature range for this crystal unit is from 0°C to 70°C, allowing for reliable performance in various conditions.
The series resistance of the ABLS-24.000MHZ-K4F-T is 100 Ω, which is important for electrical compatibility in circuits.
It comes in tape and reel packaging, making it suitable for automated assembly processes.
The frequency stability of this crystal unit is ±50 ppm, ensuring consistent performance in timing applications.
This model uses a through hole mounting type with a 2-pin configuration, facilitating easy integration into printed circuit boards.
This crystal unit is suitable for numerous electronic applications including computers, modems, microprocessors, and wireless devices.
Yes, the ABLS-24.000MHZ-K4F-T is RoHS compliant, ensuring it meets environmental safety standards.
The country of origin for this crystal unit is India.
This crystal unit belongs to the ABLS series, which is designed for precision frequency applications.
